QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 83
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
40150-40179 N70:10150-N70:10179 80151-80179
Hour/Day 2 Mode Schedule 1
(Zones 1 – 30)
0 Integer 0 23
40180-40209 N70:10180-N70:10209 80181-80209
Hour/Day 2 Mode Schedule 2
(Zones 1 – 30)
0 Integer 0 23
40210-40239 N70:10210-N70:10239 80211-80239
Hour/Day 2 Mode Schedule 3
(Zones 1 – 30)
0 Integer 0 23
40240-40269 N70:10240-N70:10269 80241-80270
Hour/Day 2 Mode Schedule 4
(Zones 1 – 30)
0 Integer 0 23
40270-40299 N70:10270-N70:10299 80271-80300
Hour/Day 2 Mode Schedule 5
(Zones 1 – 30)
0 Integer 0 23
40300-40329 N70:10300-N70:10329 80301-80330
Hour/Day 2 Mode Schedule 6
(Zones 1 – 30)
0 Integer 0 23
40330-40359 N70:10330-N70:10359 80331-80360
Hour/Day 2 Mode Schedule 7
(Zones 1 – 30)
0 Integer 0 23
40360-40389 N70:10360-N70:10389 80361-80390
Hour/Day 2 Mode Schedule 8
(Zones 1 – 30)
0 Integer 0 23
40390-40419 N70:10390-N70:10419 80391-80420
Hour/Day 3 Mode Schedule 1
(Zones 1 – 30)
0 Integer 0 23
40420-40449 N70:10420-N70:10449 80421-80450
Hour/Day 3 Mode Schedule 2
(Zones 1 – 30)
0 Integer 0 23
40450-40479 N70:10450-N70:10479 80451-80479
Hour/Day 3 Mode Schedule 3
(Zones 1 – 30)
0 Integer 0 23
40480-40509 N70:10480-N70:10509 80481-80509
Hour/Day 3 Mode Schedule 4
(Zones 1 – 30)
0 Integer 0 23
40510-40539 N70:10510-N70:10539 80511-80539
Hour/Day 3 Mode Schedule 5
(Zones 1 – 30)
0 Integer 0 23
40540-40569 N70:10540-N70:10569 80541-80570
Hour/Day 3 Mode Schedule 6
(Zones 1 – 30)
0 Integer 0 23
40570-40599 N70:10570-N70:10599 80571-80600
Hour/Day 3 Mode Schedule 7
(Zones 1 – 30)
0 Integer 0 23
40600-40629 N70:10600-N70:10629 80601-80630
Hour/Day 3 Mode Schedule 8
(Zones 1 – 30)
0 Integer 0 23
40630-40659 N70:10630-N70:10659 80631-80660
Hour/Day 3 Mode Schedule 1
(Zones 1 – 30)
0 Integer 0 23
40660-40689 N70:10660-N70:10689 80661-80690
Hour/Day 4 Mode Schedule 2
(Zones 1 – 30)
0 Integer 0 23
40690-40719 N70:10690-N70:10719 80691-80720
Hour/Day 4 Mode Schedule 3
(Zones 1 – 30)
0 Integer 0 23
40720-40749 N70:10720-N70:10749 80721-80750
Hour/Day 4 Mode Schedule 4
(Zones 1 – 30)
0 Integer 0 23
40750-40779 N70:10750-N70:10779 80751-80779
Hour/Day 4 Mode Schedule 5
(Zones 1 – 30)
0 Integer 0 23
40780-40809 N70:10780-N70:10809 80781-80809
Hour/Day 4 Mode Schedule 6
(Zones 1 – 30)
0 Integer 0 23
40810-40839 N70:10810-N70:10839 80811-80839
Hour/Day 4 Mode Schedule 7
(Zones 1 – 30)
0 Integer 0 23
40840-40869 N70:10840-N70:10869 80841-80870
Hour/Day 4 Mode Schedule 8
(Zones 1 – 30)
0 Integer 0 23
40870-40899 N70:10870-N70:10899 80871-80900
Hour/Day 5 Mode Schedule 1
(Zones 1 – 30)
0 Integer 0 23
