Frick QUANTUM LX - Page 84

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 84
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
40900-40929 N70:10900-N70:10929 80901-80930
Hour/Day 5 Mode Schedule 2
(Zones 1 – 30)
0 Integer 0 23
40930-40959 N70:10930-N70:10959 80931-80960
Hour/Day 5 Mode Schedule 3
(Zones 1 – 30)
0 Integer 0 23
40960-40989 N70:10960-N70:10989 80961-80990
Hour/Day 5 Mode Schedule 4
(Zones 1 – 30)
0 Integer 0 23
40990-41019 N70:10990-N70:11019 80991-81020
Hour/Day 5 Mode Schedule 5
(Zones 1 – 30)
0 Integer 0 23
41020-41049 N70:11020-N70:11049 81021-81050
Hour/Day 5 Mode Schedule 6
(Zones 1 – 30)
0 Integer 0 23
41050-41079 N70:11050-N70:11079 81051-81079
Hour/Day 5 Mode Schedule 7
(Zones 1 – 30)
0 Integer 0 23
41080-41109 N70:11080-N70:11109 81081-81109
Hour/Day 5 Mode Schedule 8
(Zones 1 – 30)
0 Integer 0 23
41110-41139 N70:11110-N70:11139 81111-81139
Hour/Day 6 Mode Schedule 1
(Zones 1 – 30)
0 Integer 0 23
41140-41169 N70:11140-N70:11169 81141-81170
Hour/Day 6 Mode Schedule 2
(Zones 1 – 30)
0 Integer 0 23
41170-41199 N70:11170-N70:11199 81171-81200
Hour/Day 6 Mode Schedule 3
(Zones 1 – 30)
0 Integer 0 23
41200-41229 N70:11200-N70:11229 81201-81230
Hour/Day 6 Mode Schedule 4
(Zones 1 – 30)
0 Integer 0 23
41230-41259 N70:11230-N70:11259 81231-81260
Hour/Day 6 Mode Schedule 5
(Zones 1 – 30)
0 Integer 0 23
41260-41289 N70:11260-N70:11289 81261-81190
Hour/Day 6 Mode Schedule 6
(Zones 1 – 30)
0 Integer 0 23
41290-41319 N70:11290-N70:11319 81291-81320
Hour/Day 6 Mode Schedule 7
(Zones 1 – 30)
0 Integer 0 23
41320-41349 N70:11320-N70:11349 81321-81350
Hour/Day 6 Mode Schedule 8
(Zones 1 – 30)
0 Integer 0 23
41350-41379 N70:11350-N70:11379 81351-81379
Hour/Day 7 Mode Schedule 1
(Zones 1 – 30)
0 Integer 0 23
41380-41409 N70:11380-N70:11409 81381-81409
Hour/Day 7 Mode Schedule 2
(Zones 1 – 30)
0 Integer 0 23
41410-41439 N70:11410-N70:11439 81411-81439
Hour/Day 7 Mode Schedule 3
(Zones 1 – 30)
0 Integer 0 23
41440-41469 N70:11440-N70:11469 81441-81470
Hour/Day 7 Mode Schedule 4
(Zones 1 – 30)
0 Integer 0 23
41470-41499 N70:11470-N70:11499 81471-81500
Hour/Day 7 Mode Schedule 5
(Zones 1 – 30)
0 Integer 0 23
41500-41529 N70:11500-N70:11529 81501-81530
Hour/Day 7 Mode Schedule 6
(Zones 1 – 30)
0 Integer 0 23
41530-41559 N70:11530-N70:11559 81531-81560
Hour/Day 7 Mode Schedule 7
(Zones 1 – 30)
0 Integer 0 23
41560-41589 N70:11560-N70:11589 81561-81590
Hour/Day 7 Mode Schedule 8
(Zones 1 – 30)
0 Integer 0 23
41590-41619 N70:11590-N70:11619 81591-81620
Minute/Day 1 Mode Schedule 1
(Zones 1 – 30)
0 Integer 0 59
41620-41649 N70:11620-N70:11649 81621-81650
Minute/Day 1 Mode Schedule 2
(Zones 1 – 30)
0 Integer 0 59
