Frick QUANTUM LX - Page 86

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 86
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
42400-42429 N70:12400-N70:12429 82401-82430
Minute/Day 4 Mode Schedule 4
(Zones 1 – 30)
0 Integer 0 59
42430-42459 N70:12430-N70:12459 82431-82460
Minute/Day 4 Mode Schedule 5
(Zones 1 – 30)
0 Integer 0 59
42460-42489 N70:12460-N70:12489 82461-82490
Minute/Day 4 Mode Schedule 6
(Zones 1 – 30)
0 Integer 0 59
42490-42519 N70:12490-N70:12519 82491-82520
Minute/Day 4 Mode Schedule 7
(Zones 1 – 30)
0 Integer 0 59
42520-42549 N70:12520-N70:12549 82521-82550
Minute/Day 4 Mode Schedule 8
(Zones 1 – 30)
0 Integer 0 59
42550-42579 N70:12550-N70:12579 82551-82579
Minute/Day 5 Mode Schedule 1
(Zones 1 – 30)
0 Integer 0 59
42580-42609 N70:12580-N70:12609 82581-82609
Minute/Day 5 Mode Schedule 2
(Zones 1 – 30)
0 Integer 0 59
42610-42639 N70:12610-N70:12639 82611-82639
Minute/Day 5 Mode Schedule 3
(Zones 1 – 30)
0 Integer 0 59
42640-42669 N70:12640-N70:12669 82641-82670
Minute/Day 5 Mode Schedule 4
(Zones 1 – 30)
0 Integer 0 59
42670-42699 N70:12670-N70:12699 82671-82700
Minute/Day 5 Mode Schedule 5
(Zones 1 – 30)
0 Integer 0 59
42700-42729 N70:12700-N70:12729 82701-82730
Minute/Day 5 Mode Schedule 6
(Zones 1 – 30)
0 Integer 0 59
42730-42759 N70:12730-N70:12759 82731-82760
Minute/Day 5 Mode Schedule 7
(Zones 1 – 30)
0 Integer 0 59
42760-42789 N70:12760-N70:12789 82761-82790
Minute/Day 5 Mode Schedule 8
(Zones 1 – 30)
0 Integer 0 59
43030-43059 N70:13030-N70:13059 83031-83060
Minute/Day 7 Mode Schedule 1
(Zones 1 – 30)
0 Integer 0 59
43060-43089 N70:13060-N70:13089 83061-83090
Minute/Day 7 Mode Schedule 2
(Zones 1 – 30)
0 Integer 0 59
43090-43119 N70:13090-N70:13119 83091-83120
Minute/Day 7 Mode Schedule 3
(Zones 1 – 30)
0 Integer 0 59
43120-43149 N70:13120-N70:13149 83121-83150
Minute/Day 7 Mode Schedule 4
(Zones 1 – 30)
0 Integer 0 59
43150-43179 N70:13150-N70:13179 83151-83179
Minute/Day 7 Mode Schedule 5
(Zones 1 – 30)
0 Integer 0 59
43180-43209 N70:13180-N70:13209 83181-83209
Minute/Day 7 Mode Schedule 6
(Zones 1 – 30)
0 Integer 0 59
43210-43239 N70:13210-N70:13239 83211-83239
Minute/Day 7 Mode Schedule 7
(Zones 1 – 30)
0 Integer 0 59
43240-43269 N70:13240-N70:13269 83241-83270
Minute/Day 7 Mode Schedule 8
(Zones 1 – 30)
0 Integer 0 59
43270-43299 N70:13270-N70:13299 83271-83300
Hour/Day 1 Defrost Schedule 1
(Zones 1 – 30)
0 Integer 0 23
43300-43329 N70:13300-N70:13329 83301-83330
Hour/Day 1 Defrost Schedule 2
(Zones 1 – 30)
0 Integer 0 23
43330-43359 N70:13330-N70:13359 83331-83360
Hour/Day 1 Defrost Schedule 3
(Zones 1 – 30)
0 Integer 0 23
43360-43389 N70:13360-N70:13389 83361-83390
Hour/Day 1 Defrost Schedule 4
(Zones 1 – 30)
0 Integer 0 23
