Frick QUANTUM LX - Page 87

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 87
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
43390-43419 N70:13390-N70:13419 83391-83420
Hour/Day 1 Defrost Schedule 5
(Zones 1 – 30)
0 Integer 0 23
43420-43449 N70:13420-N70:13449 83421-83450
Hour/Day 1 Defrost Schedule 6
(Zones 1 – 30)
0 Integer 0 23
43450-43479 N70:13450-N70:13479 83451-83479
Hour/Day 1 Defrost Schedule 7
(Zones 1 – 30)
0 Integer 0 23
43480-43509 N70:13480-N70:13509 83481-83509
Hour/Day 1 Defrost Schedule 8
(Zones 1 – 30)
0 Integer 0 23
43510-43539 N70:13510-N70:13539 83511-83539
Hour/Day 2 Defrost Schedule 1
(Zones 1 – 30)
0 Integer 0 23
43540-43569 N70:13540-N70:13569 83541-83570
Hour/Day 2 Defrost Schedule 2
(Zones 1 – 30)
0 Integer 0 23
43570-43599 N70:13570-N70:13599 83571-83600
Hour/Day 2 Defrost Schedule 3
(Zones 1 – 30)
0 Integer 0 23
43600-43629 N70:13600-N70:13629 83601-83630
Hour/Day 2 Defrost Schedule 4
(Zones 1 – 30)
0 Integer 0 23
43630-43659 N70:13630-N70:13659 83631-83660
Hour/Day 2 Defrost Schedule 5
(Zones 1 – 30)
0 Integer 0 23
43660-43689 N70:13660-N70:13689 83661-83690
Hour/Day 2 Defrost Schedule 6
(Zones 1 – 30)
0 Integer 0 23
43690-43719 N70:13690-N70:13719 83691-83720
Hour/Day 2 Defrost Schedule 7
(Zones 1 – 30)
0 Integer 0 23
43720-43749 N70:13720-N70:13749 83721-83750
Hour/Day 2 Defrost Schedule 8
(Zones 1 – 30)
0 Integer 0 23
43750-43779 N70:13750-N70:13779 83751-83779
Hour/Day 3 Defrost Schedule 1
(Zones 1 – 30)
0 Integer 0 23
43780-43809 N70:13780-N70:13809 83781-83809
Hour/Day 3 Defrost Schedule 2
(Zones 1 – 30)
0 Integer 0 23
43810-43839 N70:13810-N70:13839 83811-83839
Hour/Day 3 Defrost Schedule 3
(Zones 1 – 30)
0 Integer 0 23
43840-43869 N70:13840-N70:13869 83841-83870
Hour/Day 3 Defrost Schedule 4
(Zones 1 – 30)
0 Integer 0 23
43870-43899 N70:13870-N70:13899 83871-83900
Hour/Day 3 Defrost Schedule 5
(Zones 1 – 30)
0 Integer 0 23
43890-43919 N70:13890-N70:13919 83891-83920
Hour/Day 3 Defrost Schedule 6
(Zones 1 – 30)
0 Integer 0 23
43940-43969 N70:13940-N70:13969 83941-83970
Hour/Day 3 Defrost Schedule 7
(Zones 1 – 30)
0 Integer 0 23
43970-43999 N70:13970-N70:13999 83971-84000
Hour/Day 3 Defrost Schedule 8
(Zones 1 – 30)
0 Integer 0 23
44000-44029 N70:14000-N70:14029 84001-84030
Hour/Day 4 Defrost Schedule 1
(Zones 1 – 30)
0 Integer 0 23
44030-44059 N70:14030-N70:14059 84031-84060
Hour/Day 4 Defrost Schedule 2
(Zones 1 – 30)
0 Integer 0 23
44060-44089 N70:14060-N70:14089 84061-84090
Hour/Day 4 Defrost Schedule 3
(Zones 1 – 30)
0 Integer 0 23
44090-44119 N70:14090-N70:14119 84091-84120
Hour/Day 4 Defrost Schedule 4
(Zones 1 – 30)
0 Integer 0 23
44120-44149 N70:14120-N70:14149 84121-84150
Hour/Day 4 Defrost Schedule 5
(Zones 1 – 30)
0 Integer 0 23
