Frick QUANTUM LX - Page 91

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 91
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
46390-46419 N70:16390-N70:16419 86391-86420
Minute/Day 7 Defrost Schedule 1
(Zones 1 – 30)
0 Integer 0 59
46420-46449 N70:16420-N70:16449 86421-86450
Minute/Day 7 Defrost Schedule 2
(Zones 1 – 30)
0 Integer 0 59
46450-46479 N70:16450-N70:16479 86451-86479
Minute/Day 7 Defrost Schedule 3
(Zones 1 – 30)
0 Integer 0 59
46480-46509 N70:16480-N70:16509 86481-86509
Minute/Day 7 Defrost Schedule 4
(Zones 1 – 30)
0 Integer 0 59
46510-46539 N70:16510-N70:16539 86511-86539
Minute/Day 7 Defrost Schedule 5
(Zones 1 – 30)
0 Integer 0 59
46540-46569 N70:16540-N70:16569 86541-86570
Minute/Day 7 Defrost Schedule 6
(Zones 1 – 30)
0 Integer 0 59
46570-46599 N70:16570-N70:16599 86571-86600
Minute/Day 7 Defrost Schedule 7
(Zones 1 – 30)
0 Integer 0 59
46600-46629 N70:16600-N70:16629 86601-86630
Minute/Day 7 Defrost Schedule 8
(Zones 1 – 30)
0 Integer 0 59
46630-46659 N70:16630-N70:16659 86631-86660
Zone Total Run Time (Zones 1 –
30)
0 Hours 0 -1
46660-46689 N70:16660-N70:16689 86661-86690
Zone Off Suction Off Delay (Zones
1 – 30)
0 Minutes 0 100
46750-46779 N70:16750-N70:16779 86751-86779
Variable Fan Range Floor (Zones
1 – 30)
0 Percent % 0 100
46780-46809 N70:16780-N70:16809 86781-86809
Variable Fan Range Ceiling (Zones
1 – 30)
0 Percent % 0 100
46810-46839 N70:16810-N70:16839 86811-86839
Liquid Modulating Valve Range
Floor (Zones 1 – 30)
0 Percent % 0 100
46840-46869 N70:16840-N70:16869 86841-86870
Liquid Modulating Valve Range
Ceiling (Zones 1 – 30)
0 Percent % 0 100
46870-46899 N70:16870-N70:16899 86871-86900
Suction Modulating Valve Range
Floor (Zones 1 – 30)
0 Percent % 0 100
46900-46929 N70:16900-N70:16929 86901-86930
Suction Modulating Valve Range
Ceiling (Zones 1 – 30)
0 Percent % 0 100
46960-46989 N70:16960-N70:16989 86961-86990
Variable Fan Minimum Speed Cool
Cycle Mode 1 (Zones 1 – 30)
30 Percent % 0 100
46990-47019 N70:16990-N70:17019 86991-87020
Variable Fan Minimum Speed Cool
Cycle Mode 2 (Zones 1 – 30)
30 Percent % 0 100
47020-47049 N70:17020-N70:17049 87021-87050
Variable Fan Minimum Speed Cool
Cycle Mode 3 (Zones 1 – 30)
30 Percent % 0 100
47050-47079 N70:17050-N70:17079 87051-87079
Variable Fan Minimum Speed Cool
Cycle Mode 4 (Zones 1 – 30)
30 Percent % 0 100
47110-47139 N70:17110-N70:17139 87111-87139
Variable Fan Minimum Speed Heat
Cycle Mode 1 (Zones 1 – 30)
30 Percent % 0 100
47140-47469 N70:17140-N70:17469 87141-87470
Variable Fan Minimum Speed Heat
Cycle Mode 2 (Zones 1 – 30)
30 Percent % 0 100
47170-47199 N70:47470-N70:47199 87471-87200
Variable Fan Minimum Speed Heat
Cycle Mode 3 (Zones 1 – 30)
30 Percent % 0 100
