Frick QUANTUM LX - Page 92

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 92
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
47200-47229 N70:47200-N70:47229 87201-87230
Variable Fan Minimum Speed Heat
Cycle Mode 4 (Zones 1 – 30)
30 Percent % 0 100
47260-47289 N70:47260-N70:47289 87261-87290
Liquid Modulating Valve Minimum
Open Mode 1 (Zones 1 – 30)
0 Percent % 0 100
47290-47319 N70:47290-N70:47319 87291-87320
Liquid Modulating Valve Minimum
Open Mode 2 (Zones 1 – 30)
0 Percent % 0 100
47320-47349 N70:47320-N70:47349 87321-87350
Liquid Modulating Valve Minimum
Open Mode 3 (Zones 1 – 30)
0 Percent % 0 100
47350-47379 N70:47350-N70:47379 87351-87379
Liquid Modulating Valve Minimum
Open Mode 4 (Zones 1 – 30)
0 Percent % 0 100
47410-47439 N70:47410-N70:47439 87411-87439
Suction Modulating Valve Setpoint
Mode 1 (Zones 1 – 30)
40 Temp. -20 150
47440-47469 N70:47440-N70:47469 87441-87470
Suction Modulating Valve Setpoint
Mode 2 (Zones 1 – 30)
40 Temp. -20 150
47470-47499 N70:47470-N70:47499 87471-87500
Suction Modulating Valve Setpoint
Mode 3 (Zones 1 – 30)
40 Temp. -20 150
47500-47529 N70:47500-N70:47529 87501-87530
Suction Modulating Valve Setpoint
Mode 4 (Zones 1 – 30)
40 Temp. -20 150
47560-47589 N70:47560-N70:47589 87561-87590
Suction Modulating Valve Propor-
tional Band Mode 1 (Zones 1 – 30)
2
Temp.
(Magnitude)
0 100
47590-47619 N70:47590-N70:47619 87591-87620
Suction Modulating Valve Propor-
tional Band Mode 2 (Zones 1 – 30)
2
Temp.
(Magnitude)
0 100
47620-47649 N70:47620-N70:47649 87621-87650
Suction Modulating Valve Propor-
tional Band Mode 3 (Zones 1 – 30)
2
Temp.
(Magnitude)
0 100
47650-47679 N70:47650-N70:47679 87651-87679
Suction Modulating Valve Propor-
tional Band Mode 4 (Zones 1 – 30)
2
Temp.
(Magnitude)
0 100
47710-47739 N70:47710-N70:47739 87711-87739
Suction Modulating Valve Integra-
tion Time Mode 1 (Zones 1 – 30)
30 Seconds 0 999
47740-47769 N70:47740-N70:47769 87741-87770
Suction Modulating Valve Integra-
tion Time Mode 2 (Zones 1 – 30)
30 Seconds 0 999
47770-47799 N70:47770-N70:47799 87771-87800
Suction Modulating Valve Integra-
tion Time Mode 3 (Zones 1 – 30)
30 Seconds 0 999
47800-47829 N70:47800-N70:47829 87801-87830
Suction Modulating Valve Integra-
tion Time Mode 4 (Zones 1 – 30)
30 Seconds 0 999
47860-47889 N70:47860-N70:47889 87861-87890
Suction Modulating Valve Mini-
mum Open Mode 1 (Zones 1 – 30)
0 Percent % 0 100
47890-47919 N70:47890-N70:47919 87891-87920
Suction Modulating Valve Mini-
mum Open Mode 2 (Zones 1 – 30)
0 Percent % 0 100
47920-47949 N70:47920-N70:47949 87921-87950
Suction Modulating Valve Mini-
mum Open Mode 3 (Zones 1 – 30)
0 Percent % 0 100
47950-47979 N70:47950-N70:47979 87951-87979
Suction Modulating Valve Mini-
mum Open Mode 4 (Zones 1 – 30)
0 Percent % 0 100
