Frick QUANTUM LX - Page 93

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 93
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
48010-48039 N70:18010-N70:18039 88011-88039
Reheat On Temperature Mode 1
(Zones 1 – 30)
30 Temp. -20 150
48040-48069 N70:18040-N70:18069 88041-88070
Reheat On Temperature Mode 2
(Zones 1 – 30)
30 Temp. -20 150
48070-48099 N70:18070-N70:18099 88071-88100
Reheat On Temperature Mode 3
(Zones 1 – 30)
30 Temp. -20 150
48100-48129 N70:18100-N70:18129 88101-88130
Reheat On Temperature Mode 4
(Zones 1 – 30)
30 Temp. -20 150
48130-48159 N70:18130-N70:18159 88131-88160
Reheat Off Temperature Mode 1
(Zones 1 – 30)
32 Temp. -20 150
48460-48189 N70:18460-N70:18189 88461-88190
Reheat Off Temperature Mode 2
(Zones 1 – 30)
32 Temp. -20 150
48190-48219 N70:48190-N70:48219 88191-88220
Reheat Off Temperature Mode 3
(Zones 1 – 30)
32 Temp. -20 150
48220-48249 N70:48220-N70:48249 88221-88250
Reheat Off Temperature Mode 4
(Zones 1 – 30)
32 Temp. -20 150
48250-48279 N70:48250-N70:48279 88251-88279
Reheat Off Temperature Mode 5
(Zones 1 – 30)
32 Temp. -20 150
48280-48309 N70:48280-N70:48309 88281-88309
Auxiliary Analog Input # 1 High
Warning Setpoint (Zones 1 – 30)
80 None -10,000 10,000
48310-48339 N70:48310-N70:48339 88311-88339
Auxiliary Analog Input # 2 High
Warning Setpoint (Zones 1 – 30)
80 None -10,000 10,000
48340-48369 N70:48340-N70:48369 88341-88370
Auxiliary Analog Input # 3 High
Warning Setpoint (Zones 1 – 30)
80 None -10,000 10,000
48370-48399 N70:48370-N70:48399 88371-88400
Auxiliary Analog Input # 4 High
Warning Setpoint (Zones 1 – 30)
80 None -10,000 10,000
48400-48429 N70:48400-N70:48429 88401-88430
Auxiliary Analog Input # 5 High
Warning Setpoint (Zones 1 – 30)
80 None -10,000 10,000
48430-48459 N70:48430-N70:48459 88431-88460
Auxiliary Analog Input # 6 High
Warning Setpoint (Zones 1 – 30)
80 None -10,000 10,000
48460-48489 N70:48460-N70:48489 88461-88490
Auxiliary Analog Input # 7 High
Warning Setpoint (Zones 1 – 30)
80 None -10,000 10,000
48490-48519 N70:48490-N70:48519 88491-88520
Auxiliary Analog Input # 8 High
Warning Setpoint (Zones 1 – 30)
80 None -10,000 10,000
48520-48549 N70:48520-N70:48549 88521-88550
Auxiliary Analog Input # 9 High
Warning Setpoint (Zones 1 – 30)
80 None -10,000 10,000
48550-48579 N70:48550-N70:48579 88551-88579
Auxiliary Analog Input # 10 High
Warning Setpoint (Zones 1 – 30)
80 None -10,000 10,000
48580-48609 N70:48580-N70:48609 88581-88609
Auxiliary Analog Input # 1 High
Shutdown Setpoint (Zones 1 –
30)
90 None -10,000 10,000
48610-48639 N70:48610-N70:48639 88611-88639
Auxiliary Analog Input # 2 High
Shutdown Setpoint (Zones 1 –
30)
90 None -10,000 10,000
48640-48669 N70:48640-N70:48669 88641-88670
Auxiliary Analog Input # 3 High
Shutdown Setpoint (Zones 1 –
30)
90 None -10,000 10,000
48670-48699 N70:48670-N70:48699 88671-88700
Auxiliary Analog Input # 4 High
Shutdown Setpoint (Zones 1 –
30)
90 None -10,000 10,00
