Frick QUANTUM LX - Page 94

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 94
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
48700-48729 N70:48700-N70:48729 88701-88730
Auxiliary Analog Input # 5 High
Shutdown Setpoint (Zones 1 –
30)
90 None -10,000 10,000
48730-48759 N70:48730-N70:48759 88731-88760
Auxiliary Analog Input # 6 High
Shutdown Setpoint (Zones 1 –
30)
90 None -10,000 10,000
48760-48789 N70:48760-N70:48789 88761-88790
Auxiliary Analog Input # 7 High
Shutdown Setpoint (Zones 1 –
30)
90 None -10,000 10,000
48790-48819 N70:48790-N70:48819 88791-88820
Auxiliary Analog Input # 8 High
Shutdown Setpoint (Zones 1 –
30)
90 None -10,000 10,000
48820-48849 N70:48820-N70:48849 88821-88850
Auxiliary Analog Input # 9 High
Shutdown Setpoint (Zones 1 –
30)
90 None -10,000 10,000
48850-48879 N70:48850-N70:48879 88851-88879
Auxiliary Analog Input # 10 High
Shutdown Setpoint (Zones 1 –
30)
90 None -10,000 10,000
48880-48909 N70:48880-N70:48909 88881-88909
Auxiliary Analog Input # 1 High
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
48910-48939 N70:48910-N70:48939 88911-88939
Auxiliary Analog Input # 2 High
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
48940-48969 N70:48940-N70:48969 88941-88970
Auxiliary Analog Input # 3 High
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
48970-48999 N70:48970-N70:48999 88971-89000
Auxiliary Analog Input # 4 High
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
49000-49029 N70:19000-N70:19029 89001-89030
Auxiliary Analog Input # 5 High
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
49030-49059 N70:19030-N70:19059 89031-89060
Auxiliary Analog Input # 6 High
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
49060-49089 N70:19060-N70:19089 89061-89090
Auxiliary Analog Input # 7 High
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
49090-49119 N70:19090-N70:19119 89091-89120
Auxiliary Analog Input # 8 High
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
49120-49149 N70:19120-N70:19149 89121-89150
Auxiliary Analog Input # 9 High
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
49150-49479 N70:19150-N70:19479 89151-89479
Auxiliary Analog Input # 10 High
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
49480-49209 N70:19480-N70:19209 89481-89209
Auxiliary Analog Input # 1 High
Shutdown Delay (Zones 1 – 30)
60 Sec. 0 1,000
49210-49239 N70:19210-N70:19239 89211-89239
Auxiliary Analog Input # 2 High
Shutdown Delay (Zones 1 – 30)
60 Sec. 0 1,000
49240-49269 N70:19240-N70:19269 89241-89270
Auxiliary Analog Input # 3 High
Shutdown Delay (Zones 1 – 30)
60 Sec. 0 1,000
49270-49299 N70:19270-N70:19299 89271-89300
Auxiliary Analog Input # 4 High
Shutdown Delay (Zones 1 – 30)
60 Sec. 0 1,000
49300-49329 N70:19300-N70:19329 89301-89330
Auxiliary Analog Input # 5 High
Shutdown Delay (Zones 1 – 30)
60 Sec. 0 1,000
49330-49359 N70:19330-N70:19359 89331-89360
Auxiliary Analog Input # 6 High
Shutdown Delay (Zones 1 – 30)
60 Sec. 0 1,000
