QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 95
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
49360-49389 N70:19360-N70:19389 89361-89390
Auxiliary Analog Input # 7
High Shutdown Delay (Zones
1 – 30)
60 Sec. 0 1,000
49390-49419 N70:19390-N70:19419 89391-89420
Auxiliary Analog Input # 8
High Shutdown Delay (Zones
1 – 30)
60 Sec. 0 1,000
49420-49449 N70:19420-N70:19449 89421-89450
Auxiliary Analog Input # 9
High Shutdown Delay (Zones
1 – 30)
60 Sec. 0 1,000
49450-49479 N70:19450-N70:19479 89451-89479
Auxiliary Analog Input # 10
High Shutdown Delay (Zones
1 – 30)
60 Sec. 0 1,000
49480-49509 N70:19480-N70:19509 89481-89509
Auxiliary Digital Output # 1 On
Setpoint (Zones 1 – 30)
90 Temp. -10,000 10,000
49510-49539 N70:19510-N70:19539 89511-89539
Auxiliary Digital Output # 2 On
Setpoint (Zones 1 – 30)
90 Temp. -10,000 10,000
49540-49569 N70:19540-N70:19569 89541-89570
Auxiliary Digital Output # 3 On
Setpoint (Zones 1 – 30)
90 Temp. -10,000 10,000
49570-49599 N70:19570-N70:19599 89571-89600
Auxiliary Digital Output # 4 On
Setpoint (Zones 1 – 30)
90 Temp. -10,000 10,000
49600-49629 N70:19600-N70:19629 89601-89630
Auxiliary Digital Output # 5 On
Setpoint (Zones 1 – 30)
90 Temp. -10,000 10,000
49630-49659 N70:19630-N70:19659 89631-89660
Auxiliary Digital Output # 6 On
Setpoint (Zones 1 – 30)
90 Temp. -10,000 10,000
49660-49689 N70:19660-N70:19689 89661-89690
Auxiliary Digital Output # 7 On
Setpoint (Zones 1 – 30)
90 Temp. -10,000 10,000
49690-49719 N70:19690-N70:19719 89691-89720
Auxiliary Digital Output # 8 On
Setpoint (Zones 1 – 30)
90 Temp. -10,000 10,000
49720-49749 N70:19720-N70:19749 89721-89750
Auxiliary Digital Output # 9 On
Setpoint (Zones 1 – 30)
90 Temp. -10,000 10,000
49750-49779 N70:19750-N70:19779 89751-89779
Auxiliary Digital Output # 10
On Setpoint (Zones 1 – 30)
90 Temp. -10,000 10,000
49780-49809 N70:19780-N70:19809 89781-89809
Auxiliary Digital Output # 1 Off
Setpoint (Zones 1 – 30)
10 Temp. -10,000 10,000
49810-49839 N70:19810-N70:19839 89811-89839
Auxiliary Digital Output # 2
Off Setpoint (Zones 1 – 30)
10 Temp. -10,000 10,000
49840-49869 N70:19840-N70:19869 89841-89870
Auxiliary Digital Output # 3
Off Setpoint (Zones 1 – 30)
10 Temp. -10,000 10,000
49870-49899 N70:19870-N70:19899 89871-89900
Auxiliary Digital Output # 4
Off Setpoint (Zones 1 – 30)
10 Temp. -10,000 10,000
49900-49929 N70:19900-N70:19929 89901-89930
Auxiliary Digital Output # 5 Off
Setpoint (Zones 1 – 30)
10 Temp. -10,000 10,000
49930-49959 N70:19930-N70:19959 89931-89960
Auxiliary Digital Output # 6
Off Setpoint (Zones 1 – 30)
10 Temp. -10,000 10,000
49960-49989 N70:19960-N70:19989 89961-89990
Auxiliary Digital Output # 7 Off
Setpoint (Zones 1 – 30)
10 Temp. -10,000 10,000
49990-50019 N70:19990-N70:20019 89991-90020
Auxiliary Digital Output # 8
Off Setpoint (Zones 1 – 30)
10 Temp. -10,000 10,000
50020-50049 N70:20020-N70:20049 90021-90050
Auxiliary Digital Output # 9
Off Setpoint (Zones 1 – 30)
10 Temp. -10,000 10,000
