Frick QUANTUM LX - Page 96

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 96
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
50050-50079 N70:20050-N70:20079 90051-90079
Auxiliary Digital Output # 10
Off Setpoint (Zones 1 – 30)
10 Temp. -10,000 10,000
50080-50109 N70:20080-N70:20109 90081-90109
Auxiliary Analog Output # 1
PI Setpoint (Zones 1 – 30)
50 Temp. -10,000 10,000
50110-50139 N70:20110-N70:20139 90111-90139
Auxiliary Analog Output # 2
PI Setpoint (Zones 1 – 30)
50 Temp. -10,000 10,000
50140-50469 N70:20140-N70:20469 90141-90470
Auxiliary Analog Output # 3
PI Setpoint (Zones 1 – 30)
50 Temp. -10,000 10,000
50470-50199 N70:20470-N70:20199 90471-90200
Auxiliary Analog Output # 4
PI Setpoint (Zones 1 – 30)
50 Temp. -10,000 10,000
50200-50229 N70:20200-N70:20229 90201-90230
Auxiliary Analog Output # 1
Prop Band (Zones 1 – 30)
2
Temp
(Magnitude)
0 1,000
50230-50259 N70:20230-N70:20259 90231-90260
Auxiliary Analog Output # 2
Prop Band (Zones 1 – 30)
2
Temp
(Magnitude)
0 1,000
50260-50289 N70:20260-N70:20289 90261-90290
Auxiliary Analog Output # 3
Prop Band (Zones 1 – 30)
2
Temp
(Magnitude)
0 1,000
50290-50319 N70:20290-N70:20319 90291-90320
Auxiliary Analog Output # 4
Prop Band (Zones 1 – 30)
2
Temp
(Magnitude)
0 1,000
50320-50349 N70:20320-N70:20349 90321-90350
Auxiliary Analog Output #
1 Integration Time (Zones
1 – 30)
30 Sec. 0 1,000
50350-50379 N70:20350-N70:20379 90351-90379
Auxiliary Analog Output #
2 Integration Time (Zones
1 – 30)
30 Sec. 0 1,000
50380-50409 N70:20380-N70:20409 90381-90409
Auxiliary Analog Output #
3 Integration Time (Zones
1 – 30)
30 Sec. 0 1,000
50410-50439 N70:20410-N70:20439 90411-90439
Auxiliary Analog Output #
4 Integration Time (Zones
1 – 30)
30 Seconds 0 1,000
50440-50469 N70:20440-N70:20469 90441-90470
Auxiliary Analog Output # 1
Range Floor (Zones 1 – 30)
0 Percent % -10,000 10,000
50470-50499 N70:20470-N70:20499 90471-90500
Auxiliary Analog Output # 2
Range Floor (Zones 1 – 30)
0 Percent % -10,000 10,000
50500-50529 N70:20500-N70:20529 90501-90530
Auxiliary Analog Output # 3
Range Floor (Zones 1 – 30)
0 Percent % -10,000 10,000
50530-50559 N70:20530-N70:20559 90531-90560
Auxiliary Analog Output # 4
Range Floor (Zones 1 – 30)
0 Percent % -10,000 10,000
50560-50589 N70:20560-N70:20589 90561-90590
Auxiliary Analog Output # 1
Range Ceiling (Zones 1 – 30)
100 Percent % -10,000 10,000
50590-50619 N70:20590-N70:20619 90591-90620
Auxiliary Analog Output # 2
Range Ceiling (Zones 1 – 30)
100 Percent % -10,000 10,000
50620-50649 N70:20620-N70:20649 90621-90650
Auxiliary Analog Output # 3
Range Ceiling (Zones 1 – 30)
100 Percent % -10,000 10,000
50650-50679 N70:20650-N70:20679 90651-90679
Auxiliary Analog Output # 4
Range Ceiling (Zones 1 – 30)
100 Percent % -10,000 10,000
50680-50709 N70:20680-N70:20709 90681-90709
Auxiliary Analog Output # 1
Minimum Open (Zones 1 –
30)
0 Percent % -10,000 10,000
