Frick QUANTUM LX - Page 97

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 97
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
50710-50739 N70:20710-N70:20739 90711-90739
Auxiliary Analog Output # 2
Minimum Open (Zones 1 – 30)
0
Percent
%
-10,000 10,000
50740-50769 N70:20740-N70:20769 90741-90770
Auxiliary Analog Output # 3
Minimum Open (Zones 1 – 30)
0
Percent
%
-10,000 10,000
50770-50799 N70:20770-N70:20799 90771-90800
Auxiliary Analog Output # 4
Minimum Open (Zones 1 – 30)
0
Percent
%
-10,000 10,000
50800-50829 N70:20800-N70:20829 90801-90830
Max Number of Zones in Defrost
(Group 1)
3 None 1 100
50830-50859 N70:20830-N70:20859 90831-90860
Number of Zones Currently in
Defrost (Group 1)
0 None 0 100
50860-50889 N70:20860-N70:20889 90861-90890
Max Hours Between Defrosts
(Zones 1 – 30)
36 Hours 0 500
50920-50949 N70:20920-N70:20949 90921-90950
Dehumidication Entry Low
Temperature Threshold Mode 1
(Zones 1 – 30)
32 Temp. -20 150
50950-50979 N70:20950-N70:20979 90951-90979
Dehumidication Entry Low
Temperature Threshold Mode 2
(Zones 1 – 30)
32 Temp. -20 150
50980-51009 N70:20980-N70:21009 90981-91009
Dehumidication Entry Low
Temperature Threshold Mode 3
(Zones 1 – 30)
32 Temp. -20 150
51010-51039 N70:21010-N70:21039 91011-91139
Dehumidication Entry Low
Temperature Threshold Mode 4
(Zones 1 – 30)
32 Temp. -20 150
51040-51069 N70:21040-N70:21069 91041-91070
Fan Auxiliary Shutdown Delay
(Zones 1 – 30)
20 Sec. 0 1,000
51100-51129 N70:21100-N70:21129 91101-91130
High Temperature Warning Delay
Mode 1 (Zones 1 – 30)
60 Sec. 0 1,000
51130-51159 N70:21130-N70:21159 91131-91160
High Temperature Warning Delay
Mode 2 (Zones 1 – 30)
60 Sec. 0 1,000
51460-51489 N70:21460-N70:21489 91461-91490
High Temperature Warning Delay
Mode 3 (Zones 1 – 30)
60 Sec. 0 1,000
51190-51219 N70:21190-N70:21219 91191-91220
High Temperature Warning Delay
Mode 4 (Zones 1 – 30)
60 Sec. 0 1,000
51250-51279 N70:21250-N70:21279 91251-91279
Low Temperature Warning Delay
Mode 1 (Zones 1 – 30)
60 Sec. 0 1,000
51280-51309 N70:21280-N70:21309 91281-91309
Low Temperature Warning Delay
Mode 2 (Zones 1 – 30)
60 Sec. 0 1,000
51310-51339 N70:21310-N70:21339 91311-91339
Low Temperature Warning Delay
Mode 3 (Zones 1 – 30)
60 Sec. 0 1,000
51340-51369 N70:21340-N70:21369 91341-91370
Low Temperature Warning Delay
Mode 4 (Zones 1 – 30)
60 Sec. 0 1,000
51400-51429 N70:21400-N70:21429 91401-91430
High Temperature Warning Temp
Mode 1 (Zones 1 – 30)
100 Temp. -20 150
51430-51459 N70:21430-N70:21459 91431-91460
High Temperature Warning Temp
Mode 2 (Zones 1 – 30)
100 Temp. -20 150
