32
Fan for checking the fan functionality
- Use the "Up" and "Down" keys to select Test fan #1
- Press the "Enter" key to start testing of the fans
- The fans run until the menu is exited by pressing the "Esc" key
Arc Detection for checking arc detection/interruption
Setting range Test fan #1 / Test fan #2
Setting range ArcDetector Status/Start Self-test
Arc.det. Status
displays the current status of arc detection/interruption
Start Self-test
self-test to check whether the inverter interrupts grid power feed operation when an arc
is detected.
Test procedure:
Select "Arc Detection" in the Setup menu
Press the "Enter" key
Use the up and down keys to select "Start Self-test"
Press the "Enter" key
The self-test starts. The arc detection/interruption function simulates an arc and sends
the corresponding signal to the inverter.
If the test is successful, the inverter disconnects from the grid and stops grid power feed
operation.
The message "Self-test completed and Start AFCI" is shown on the display.
Confirm the indication by pressing the "Enter" key
1
2
3
4
5

Fronius Primo Series Specifications

General

Efficiency	Up to 98.1%
Protection Rating	IP65
Operating Temperature Range	-25°C to +60°C
Frequency	50 / 60 Hz
DC input voltage range	80 - 600 V
Model	Primo Series
Type	Transformerless
Power Classes	3.0 kW to 8.2 kW
Communication Interfaces	WLAN, Ethernet, RS485
Weight	21.5 kg
Max. apparent AC power	8, 200 VA
AC voltage range	150 - 280 V
MPP voltage range	240 - 480 V
Warranty	5 years
Dimensions	645 x 431 x 204 mm
