Fronius Primo Series User Manual

40
Items in the Basic
Menu
The Basic menu contains the following items:
MPP Tracker 1 DC Tracking Mode:
MPP AUTO
FIX
MPP USER
Dyn. Peak Manager:
ON / OFF
Fix PV Voltage:
For entering the fixed voltage, 150 - 800 V
MPPT1 Start Voltage:
For entering the MPPT1 initial voltage, 150 - 800 V
MPP Tracker 2 MPP Tracker 2:
ON / OFF
DC operating mode:
MPP AUTO
FIX
MPP USER
Dyn. Peak Manager:
ON / OFF
Fix PV Voltage:
For entering the fixed voltage, 150 - 800 V
MPPT2 Start Voltage:
For entering the MPPT2 initial voltage, 150 - 800 V
USB Eventlog Activating or deactivating the function to save all error messag-
es to a USB stick
AUTO / OFF / ON
Input Signal Mode of operation:
Ext Sig. / S0-Meter / OFF
Trigger response (at Mode of operation „Ext. Sig.“):
Warning / Ext. Stop
Connection type (at Mode of operation „Ext. Sig.“):
N/C / N/O
SMS / Relay Event Delay:
For entering the delay time from when an SMS is sent or from
when the relay should switch
900–86400 seconds
Event Counter:
For entering the number of errors following which an SMS is
sent or the relay should switch:
10–255

Fronius Primo Series Specifications

General

Efficiency	Up to 98.1%
Protection Rating	IP65
Operating Temperature Range	-25°C to +60°C
Frequency	50 / 60 Hz
DC input voltage range	80 - 600 V
Model	Primo Series
Type	Transformerless
Power Classes	3.0 kW to 8.2 kW
Communication Interfaces	WLAN, Ethernet, RS485
Weight	21.5 kg
Max. apparent AC power	8, 200 VA
AC voltage range	150 - 280 V
MPP voltage range	240 - 480 V
Warranty	5 years
Dimensions	645 x 431 x 204 mm
