Fronius Primo Series User Manual

38
USB Stick for Up-
dating Inverter
Software
The USB stick can be used to help end customers update inverter software via the USB
menu item in the SETUP menu item: the update file is first saved on the USB stick and then
transferred to the inverter. The update file must be saved in the USB stick root directory.
Removing the
USB Stick
NOTE! Please be aware that in outdoor applications the USB stick may only func-
tion in a limited temperature range. Make sure, for example, that the USB stick
will also function at low temperatures for outdoor applications.
Safety information for removing a USB stick
IMPORTANT! To prevent a loss of data,
the connected USB stick should only be
removed under the following conditions:
- via the SETUP and "Safely remove
USB / hardware" menu items
- when the "Data Transfer" LED is no
longer flashing or illuminated.
Do not disconnect
USB-Stick
while LED is flashing!
X

Fronius Primo Series Specifications

General

Efficiency	Up to 98.1%
Protection Rating	IP65
Operating Temperature Range	-25°C to +60°C
Frequency	50 / 60 Hz
DC input voltage range	80 - 600 V
Model	Primo Series
Type	Transformerless
Power Classes	3.0 kW to 8.2 kW
Communication Interfaces	WLAN, Ethernet, RS485
Weight	21.5 kg
Max. apparent AC power	8, 200 VA
AC voltage range	150 - 280 V
MPP voltage range	240 - 480 V
Warranty	5 years
Dimensions	645 x 431 x 204 mm
