Fronius Primo Series User Manual

41
EN-US
Insulation settings Insulation warning:
to activate and deactivate the insulation monitoring with dis-
play of a warning without interrupting feed-in in the event of an
insulation error
ON / OFF (depends on the country setup)
Threshold warning:
to set an insulation threshold below which the inverter displays
a warning (without interrupting feed-in)
depends on the country setup set
Threshold error:
to set an insulation threshold under which the inverter displays
an error message and interrupts feed-in
depends on the country setup
TOTAL Reset ... resets the max. and min. voltage values and the max. power
of feeding in in the LOG menu item to zero.
Once you have reset the values, this cannot be undone.
To reset the values to zero, press the "Enter" key.
"CONFIRM" is displayed.
Press the "Enter" key again.
The values are reset and the menu is displayed.

Fronius Primo Series Specifications

General

Efficiency	Up to 98.1%
Protection Rating	IP65
Operating Temperature Range	-25°C to +60°C
Frequency	50 / 60 Hz
DC input voltage range	80 - 600 V
Model	Primo Series
Type	Transformerless
Power Classes	3.0 kW to 8.2 kW
Communication Interfaces	WLAN, Ethernet, RS485
Weight	21.5 kg
Max. apparent AC power	8, 200 VA
AC voltage range	150 - 280 V
MPP voltage range	240 - 480 V
Warranty	5 years
Dimensions	645 x 431 x 204 mm
