Fronius Primo Series User Manual

53
EN-US
Output frequency range
Setups: 50Hz, 60Hz
Setup: HI1
48.0 - 50.5 Hz / 59.3 - 60.5 Hz
- / 57.0 - 63.0 Hz
Setting range for grid frequency 45.0 - 55.0 Hz / 50.0 - 65.0 Hz
Frequency limit accuracy 0.05 Hz
Frequency clearing times setting range 0.016 - 600 s
Total harmonic distortion < 5 % < 2.5 %
Power factor (cos phi) 0.85 - 1 ind./cap..
1)
0 - 1 ind./cap..
1)
General data
Maximum efficiency 97.9 % 97.9 %
CEC efficiency at 208 V
at 220 V
at 240 V
97.0 %
97.0 %
97.0 %
97.0 %
97.0 %
97.0 %
97.0 %
97.0 %
97.0 %
Night self-consumption at 208 V
at 220 V
at 240 V
0.4 W
0.6 W
0.6 W
Self-consumption during operation 10 W
Cooling Forced-air ventilation
Degree of protection NEMA4X
Dimensions l x h x w 24.7/16.9/8.1 inch
628/428/205 mm
28.5/20.1/8.9 inch
725/510/225 mm
Weight 42.0 lbs. (21.45 kg) 82.5 lbs. (37.4 kg)
Shipping dimensions l x h x w 30.1/21.7/11.4 inch
770/550/290 mm
31.1/22.6/13.4 in.
790/575/340 mm
Shipping weight 57.6 lbs. (26.11 kg) 90.2 lbs. (40.9 kg)
Permissible ambient temperature
(at 95% rel. humidity)
-40 °F - +131 °F
(-40 °C - +55°C)
-40 °F - +140 °F
(-40 °C - +60°C)
Permissible storage temperature
(with 95% rel. humidity)
-40 °F - +158 °F (-40 °C - +70°C)
Protection devices
Insulation monitoring Integrated
Stand alone operation protection Integrated
Reverse polarity protection Integrated
Arc Detector / Interrupter Integrated
Overtemperature Operating point offset / active cooling
1) Ind. = inductive cap. = capacitive
Fronius Primo 7.6-1 208-240 8.2-1 208-240 10.0-1 208-240

Fronius Primo Series Specifications

General

Efficiency	Up to 98.1%
Protection Rating	IP65
Operating Temperature Range	-25°C to +60°C
Frequency	50 / 60 Hz
DC input voltage range	80 - 600 V
Model	Primo Series
Type	Transformerless
Power Classes	3.0 kW to 8.2 kW
Communication Interfaces	WLAN, Ethernet, RS485
Weight	21.5 kg
Max. apparent AC power	8, 200 VA
AC voltage range	150 - 280 V
MPP voltage range	240 - 480 V
Warranty	5 years
Dimensions	645 x 431 x 204 mm
