Display
Overview of dis-
play modes
The device has the following display modes:
No. Function
Standard mode
In standard mode the display shows the charging parameters.
Statistics mode
Visualises the frequency of the device operating modes and shows the
total number of charging actions. Also shows an overview of the total
and average Ah produced and energy consumed per charge.
History mode
Provides information about the parameters for all the stored charging
processes.
Configuration mode
Configuration mode enables all the settings for the device and the
charging process to be adjusted.
USB mode
USB mode enables a device to be updated, device configurations to be
saved and loaded, and the charging parameters to be recorded during
the charging process - all using a USB flash drive.
As long as a battery is connected to the charger, the charging process can only
be interrupted and resumed using the "Pause/Start" key. Display modes can be
changed using the "Menu" key as described in the following sections that explain
the individual modes, but this is only possible when there is no battery connected
to the charger.
During a pause in the charging process the menu selection is available, however
only in a limited form. In this case the display modes described below are avail-
able as follows:
Statistics mode and history mode remain unrestricted.
In configuration mode the following data is available:
-
Date and time
-
Device serial number
-
Hardware version and serial number
-
Software: main software, secondary software, primary software and charac-
teristic block version
In USB mode all options except for "Update" and "Load configuration" are avail-
able.
Standard mode Once the mains plug has been connected to the electrical mains supply, the dis-
play will automatically operate in standard mode.
