Technical data
Special voltages
CAUTION!
An inadequately dimensioned electrical installation can cause serious damage.
▶
The mains lead and its fuse must be dimensioned accordingly.
The technical data shown on the rating plate applies.
Overview with
critical raw ma-
terials, year of
production of
the device
Overview with critical raw materials:
An overview of which critical raw materials are contained in this device can be
found at the following Internet address.
www.fronius.com/en/about-fronius/sustainability.
To calculate the year of production of the device:
-
Each device is provided with a serial number
-
The serial number consists of 8 digits - for example 28020099
-
The first two digits give the number from which the year of production of the
device can be calculated
-
This figure minus 11 gives the year of production
-
For example: Serial number = 28020065, calculation of the year of pro-
duction = 28 - 11 = 17, year of production = 2017
MagicWave 1700
Mains voltage 230 V
Mains voltage tolerance -20% / +15%
Grid frequency 50/60 Hz
Mains fuse protection (slow-blow) 16 A
Mains connection
1)
Restrictions pos-
sible
Primary continuous power (100% D.C.
2)
)
3.3 kVA
Cos phi 0.99
Welding current range
TIG 3 - 170 A
Electrode 10 - 140 A
Welding current at
10 min/25 °C (77 °F) 40% D.C.
2)
170 A
10 min/25 °C (77 °F) 60% D.C.
2)
140 A
10 min/25 °C (77 °F) 100% D.C.
2)
110 A
10 min/40 °C (104 °F) 35% D.C.
2)
170 A
10 min/40 °C (104 °F) 60% D.C.
2)
130 A
10 min/40 °C (104 °F) 100% D.C.
2)
100 A
Open circuit voltage 88 V
100
