Fronius TransTig 1700 User Manual

Welding current range (3-phase)
TIG 3 - 300 A
Electrode 10 - 300 A
Welding current range (single phase)
TIG 3 - 220 A
Electrode 10 - 180 A
Welding current at 3 x 400 - 460 V
10 min/40 °C (104 °F) 35% D.C.
2)
300 A
10 min/40 °C (104 °F) 40% D.C.
2)
-
10 min/40 °C (104 °F) 100% D.C.
2)
190 A
Welding current at 3 x 200 - 240 V
10 min/40 °C (104 °F) 30% D.C.
2)
300 A
10 min/40 °C (104 °F) 35% D.C.
2)
-
10 min/40 °C (104 °F) 100% D.C.
2)
180 A
Welding current at 1 x 200 - 240 V
10 min/40 °C (104 °F) 40% D.C.
2)
-
10 min/40 °C (104 °F) 50% D.C.
2)
220 A
10 min/40 °C (104 °F) 100% D.C.
2)
160 A
Open circuit voltage 89 V
Working voltage
TIG 10.1 - 22.0 V
Electrode 20.4 - 32.0 V
Striking voltage (U
p
) 10 kV
The arc striking voltage is suitable for manual operation.
Degree of protection IP 23
Type of cooling AF
Insulation class B
EMC device class
(in accordance with EN/IEC 60974-10)
A
Dimensions L/W/H (with handle) 560 / 250 / 435 m
m
22.0 / 9.8 / 17.1 in.
Weight 30 kg
66.14 lb.
Mark of conformity S, CE
Idle state power consumption at 400 V 47.4 W
Power source efficiency at 300 A / 32.0 V 83%
MagicWave 4000
Mains voltage 3 x 400 V
106
