Type of cooling AF
Insulation class B
EMC device class
(in accordance with EN/IEC 60974-10)
A
Dimensions L/W/H (with handle) 560 / 250 / 435 m
m
22.0 / 9.8 / 17.1 in.
Weight 26.6 kg
58.64 lb.
Mark of conformity S, CE
Idle state power consumption at 400 V 50.0 W
Power source efficiency at 250 A / 30.0 V 83%
MagicWave 3000
Mains voltage 3 x 400 V
Mains voltage tolerance ± 15%
Grid frequency 50/60 Hz
Mains fuse protection (slow-blow) 16 A
Mains connection
1)
Z
max
on PCC
3)
= 87 mOhm
Primary continuous power (100% D.C.
2)
)
5.5 kVA
Cos phi 0.99
Welding current range
TIG 3 - 300 A
Electrode 10 - 300 A
Welding current at
10 min/40 °C (104 °F) 35% D.C.
2)
300 A
10 min/40 °C (104 °F) 40% D.C.
2)
-
10 min/40 °C (104 °F) 100% D.C.
2)
200 A
Open circuit voltage 89 V
Working voltage
TIG 10.1 - 22.0 V
Electrode 20.4 - 32.0 V
Striking voltage (U
p
) 10 kV
The arc striking voltage is suitable for manual operation.
Degree of protection IP 23
Type of cooling AF
Insulation class B
EMC device class
(in accordance with EN/IEC 60974-10)
A
103
