TIG setup menu
Opening the TIG
set-up menu
1
Press the Mode button to select 2-step mode or 4-step mode
2
Press and hold the "Mode" button
3
Press the right parameter selection button
The power source is now in the TIG set-up menu. The last welding
parameter selected is displayed.
Changing weld-
ing parameters
1
Use the left or right parameter selection button to select the
welding parameter that you want to change
2
Use the adjusting dial to change the welding parameter value
Exiting the set-
up menu
1
Press the Mode button
Welding para-
meters in the
TIG setup menu
"Minimum" and "maximum" are used for setting ranges that differ according to
power source, wirefeeder, welding program, etc.
tAC
Tacking function for the TIG DC welding process: Duration of the pulsed weld-
ing current at the start of tacking
Unit s
Setting range OFF / 0.1 - 9.9 / ON
Factory setting OFF
ON The pulsed welding current remains in effect until the
end of the tacking operation
0.1 - 9.9 s The set time begins with the UpSlope phase. After the
end of the pre-set time period, welding continues at a
constant current; any pulsing parameters that have been
set are available.
OFF The tacking function is deactivated
78
