Connecting up the mains cable on US power
sources
General The US power sources are supplied without a mains cable. A mains cable appro-
priate for the connection voltage must be fitted prior to commissioning.
A strain-relief device for a cable cross-section AWG 10 is installed on the power
source. Strain-relief devices for larger cable cross-sections must be designed ac-
cordingly.
Stipulated mains
cables and
strain-relief
devices
Power source Mains voltage Cable cross-sec-
tion
TT 4000/5000 MV Job, MW
4000/5000 MV Job
3 x 380 - 460 V
3 x 200 - 240 V
AWG 10
AWG 6
AWG ... American Wire Gauge
Safety
WARNING!
Danger due to work that has been carried out incorrectly.
This can result in serious injury and damage to property.
The work described below must only be carried out by trained and qualified
personnel.
Observe national standards and directives.
CAUTION!
Danger due to improperly prepared mains cable.
This can cause short circuits and damage.
Fit ferrules to all phase conductors and the ground conductor of the
stripped mains cable.
Connecting the
mains cable
1
Remove the left side panel of the power source
2
Strip about 100 mm (4 in.) of insulation from the end of the mains cable
NOTE!
The ground conductor (green, or green with yellow stripes) should be ap-
prox. 10 - 15 mm (0.4 - 0.6 in.) longer than the phase conductors.
50
