Fronius TransTig 1700 User Manual

Welding current at
10 min/25 °C (77 °F) 50% D.C.
2)
-
10 min/25 °C (77 °F) 60% D.C.
2)
-
10 min/25 °C (77 °F) 100% D.C.
2)
80 A
10 min/40 °C (104 °F) 40% D.C.
2)
-
10 min/40 °C (104 °F) 60% D.C.
2)
80 A
10 min/40 °C (104 °F) 100% D.C.
2)
70 A
Open circuit voltage 85 V
Working voltage
TIG 10.0 - 13.2 V
Electrode 10.4 - 23.2 V
Striking voltage (U
p
) 9.0 kV
The arc striking voltage is suitable for manual operation.
Degree of protection IP 23
Type of cooling AF
Insulation class B
EMC device class
(in accordance with EN/IEC 60974-10)
A
Dimensions L/W/H (with handle) 485 / 180 / 344 m
m
19.1 / 7.1 / 13.5 in.
Weight (without handle) 14.2 kg
31.3 lb.
Weight (with handle) -
-
Mark of conformity S, CE
Idle state power consumption at 230 V 23.1 W
Power source efficiency at 80 A / 23.2 V 81%
TransTig 2200
Mains voltage 230 V
Mains voltage tolerance -20% / +15%
Grid frequency 50/60 Hz
Mains fuse protection (slow-blow) 16 A
Mains connection
1)
No restrictions
Primary continuous power (100% D.C.
2)
)
3.0 kVA
Cos phi 0.99
Welding current range
TIG 3 - 220 A
Electrode 10 - 180 A
111
