Frymaster easyTouch FilterQuick FQG60T - Installing the Oil Saddle Reservoir

2-11
DANGER
Adequate means must be provided to limit the movement of this appliance without depending
on the connector and the quick-disconnect device or its associated piping to limit the appliance
movement.
2. Close fryer drain-valve(s).
3. Clean and fill frypot(s) to the bottom oil level line with cooking oil. (See Equipment Setup and Shut-
down Procedures in Chapter 3.)
2.7 Installing the Optional Oil Saddle Reservoir
Carefully cut the shipping strap around the oil saddle hose on the rear of the
fryer. Attach the hose to the oil saddle reservoir quick disconnect on the bottom
of the reservoir. Lift up the or-
ange quick disconnect and insert
the male adaptor of the hose.
Once the male end is fully insert-
ed, release the quick disconnect
to attach. Once attached, pull
gently on the hose to ensure it is
connected (see Figure 1).
Using the enclosed strap, attach
to the saddle hose as shown. At-
tach to the oil saddle handle to
keep the hose off of the floor (see
Figure 2).
Figure 1
Figure 2
