2.5.2 Component Boxes cont.
ITEM PART # COMPONENT
1 810-1164 Block, One-Piece Screwless Terminal
2 816-0217 Insulation, Terminal Block Paper
√ 3 807-3843 Fuse 3A 250V Domestic
√ * 826-1157 Kit, Fuse and Fuse Puller (2 Fuses)
807-3293
Fuse 5A 125V International Only
* 106-0531SP Fuse Assy, Inline
√ 4 807-5008 Cable, 21-inch Ignition – For 807-3366/807-3365 Modules
* 807-5009 Cable, Ignition 19” (CE)
* 807-3484 Connector, Rajah
5 807-4199 Cable, 20-pin Controller to 15-pin Interface Board – SMT for fryers with CM 3.5 control-
ler.
* 807-5165 Cable, 20-pin Controller to 15-pin Interface Board – SMT for fryers with 3000 controller.
6 806-6085SP Wire Assembly, Ignitor
7 220-6102 Box, One-Piece Component
√ 8 807-2971 Ignition Module, (Australia)
√ 9 807-1006 Ignition Module, CE
√ 10 8073366† Ignition Module, Honeywell Dual-Spark Full-Vat (Domestic and Non-CE export unit
except Australia)
√ 8073365† Ignition Module, Honeywell Single-Spark Dual-Vat (Domestic and Non-CE export unit
except Australia)
√ 8075949 Ignition Module, Fenwal Single-Spark Full/Dual-Vat (Domestic and Non-CE export unit
except Australia) (Use 8263446 for a Conversion Kit – NOTE: 2 kits are needed to con-
vert a Full Vat.)
√ 11 826-2264 Interface Board Kit SMT
807-4330 Speaker Adapter Harness SMT
807-4343 Wire Harness, SMT Interface Board to Ignition Module
√ 12 807-0833
Relay, DPDT 5A 12VDC Latch (See NOTE 1.)
√ 13 807-0834
Relay, SPDT 15A 12VDC Basket Lift (See NOTE 2.)
14 810-2243 Spring, Relay Retaining
15 108-1094 Plate, Ignition Module
16 824-2090 Cover, Ignition Module
17 824-2091 Cover, Ignition Module CE
18 220-7085 Cover, Ignition Module Australia
19 108-1544 Plate, Ignition Module Australia
20 807-1683 Relay, 12VDC Secondary Blower Fan to cool frypot
21 106-0531SP Fuse Assembly, Inline (not used on all models)
* 807-2659 Switch, Momentary (Control Power Reset, only used in far left component box)
* 807-4403 Speaker SMT
22 108-1260 Wire Assembly, Ignition Module Domestic and Non-CE export, except Australia.
108-2353 Wire Assembly, Ignition Module CE
23 806-4973 Interface Board, Australia
24 108-2581 Harness, Secondary Blower
* Not illustrated.
√ Recommended parts.
† For Full-vat units, use one 807-3366 Dual Spark Ignition Module (see NOTE 1).
† For Dual-vat units, use two 807-3365 Single Spark Ignition Modules (see NOTE 1).
NOTE 1: U.S., Canadian, and Mexican units use two different modules depending upon the configuration of the frypot.
Full-Vat units use one 807-3366 Dual-Spark Ignition Module while Dual-Vat units use two 807-3365 Single-Spark Igni-
tion Modules. Also, in full-vat units, only two latch relays (Item 12) are used, located in the sockets on the right side of
the interface board. These relays are located in the bottom sockets of the interface board and control the heating circuit.
NOTE 2: The relays in the top sockets control the basket lifts (Item 13) and are present only on units equipped with
basket lifts.
