2-13
2.6.2 3000 and ATO Wiring Harnesses (Refer to wiring diagram on page 1-50.)
ITEM PART # COMPONENT
* 807-4546 Controller Communication (used from controller to controller)
* 807-4646 Controller Communication (used from right controller to ATO box)
* 807-4655 Harness RTD Medium (used from ATO RTD to ATO Board)
* 826-2569 FV/DV ATO/RTD Probe Kit
* 807-4553 ATO Power (used from transformer to ATO board #1)
* 807-5163 ATO Power ATO Secondary Box (used from transformer to ATO board #2)
* 807-4719
ATO Pump and JIB (used from ATO Board to Top-off Pump and JIB Reset
Switch)
* 807-5161
Harness, ATO Solenoid, Pump Relay Primary (used from ATO Board to Top-off
Pump Relay, Solenoids, and JIB Reset Switch)
* 807-5162
Harness, Secondary ATO Solenoid, Pump Relay (used in second ATO box on 4
battery fryers from ATO Board to Top-off Pump Relay and Solenoids)
* 807-4573
Controller Locator Wire (used from controller to interface board) See wiring dia-
gram 805-1855 on page 1-51 for locator pin positions.
* 807-4552
Communications Terminator (used on controller pin J6 and ATO board pin J10 to
terminate network)
807-4657 Jumper (used on 4 and 5 battery ATO board plug J5 pin 7 and 8)
* 106-9544 Long Top-off Power (used between ATO box #1 and #2)
√ * 807-4660PK SMT Pin Service Repair Kit
√ * 230-2345 SMT Pin Extractor
* Not illustrated.
√ Recommended parts.
See page 1-30 and 1-39 for Pin Positions.
