2.5.3 Transformer Boxes cont.
ITEM PART # COMPONENT
√ 6 807-4346 Relay, DPDT 20A 120VAC (Control Reset Button) (used for control power reset in
domestic units)
√ 807-4770 Relay, DPDT 20A 240V (used for control power reset in international units)
√ 7 807-0012 Relay, Filter 18A 24VAC
8 816-0217 Insulation, Terminal Block Paper
9 810-1164 Block, One-Piece Screwless Terminal
√ 10 807-1597 Fuse, 3amp Slo-Blow
11 807-1973 Terminal, Post
12 807-0070 Terminal, Ground Lug
13 220-3191 Cover, Large Transformer Box
14 823-6324 Box, Large Transformer/Filter
15 108-1728 Cable Assembly, Transformer Box Line GL230, 330, 430, 230 and 330 CE Export
and 430 CE Export Filter Pump
16 106-8168 Cable Assembly, Transformer Box Line GL230 CE Export
17 106-8170 Cable Assembly, Transformer Box Filter Pump GL230, 330, 230 and 330 CE Export
18 108-0994 Cable Assembly, Transformer Box #1 GL230,330, 230 and 330 CE Export
19 108-0995 Cable Assembly, Transformer Box #2 GL230, 330, 230 and 330 CE Export
20 108-0996 Cable Assembly, Transformer Box #3 GL330 and 330 CE Export
21 108-1778 Harness Assembly, Vat # 4
22 108-1777 Harness Assembly, Vat # 3
23 108-1789 Harness Assembly, 4 Batt Cordset
24 823-7638 Box, Transformer/Filter GL30 4-Battery
* WIR 0798 Wire Assembly, GL230/330 Transformer/Filter Box (used in Items A, B, C and D)
* WIR 0957 Wire Assembly, GL230/430 (used in Items A, B, C and D)
* WIR 0958 Wire Assembly, GL 430 (used in Item E)
* 108-3433 Harness, Bulk Oil Jumper
* 108-3432 Harness, T-Box Gas OCF
* Not illustrated
√ Recommended parts.
