Frymaster FPGL330CA - Page 82

2-15
2.7.1 Full-Vat Frypot Components cont.
ITEM PART # COMPONENT
108-2222SP Frypot Assy Full-Vat OCF with filter (NAT)
108-2224 Frypot Assy Full-Vat OCF with filter (PRO)
108-2849 Frypot Assy Full-Vat OCF non-filter (NAT)
108-2848 Frypot Assy Full-Vat OCF non-filter (PRO)
826-2595 Insulation Kit, Complete Full-Vat
826-2592 Insulation Kit, Burner Full-Vat
1 108-2897 Flue Assembly, Full-Vat
2 220-6470 Back, Lower Full-Vat Combustion Chamber
3 220-6529 Retainer, Full-Vat Upper Insulation
4 220-7831 Retainer, Outer Frypot
5 230-6960 Plate, FV Collector Mounting
6 220-2851 Brace, FV Rear Insulation
7 220-2920 Brace, Foam Deck Insulation
√ 8 810-3435 Burner, Universal Replacement
9 812-0356 Insulation, Burner Sight Glass
10 816-0900 Insulation, Burner
11 812-0706 Insulation, Upper Burner Rail
12 812-1029 Insulation, Combustion Chamber Side
13 814-0048SP Glass, Burner Sight
14 816-0837 Insulation, FV Rear Lower
15 816-0731 Insulation, FV LH/RH Front Seal
16 816-0732 Insulation, FV Lower Inner Front
17 816-0733 Insulation, FV Front Upper
18 816-0978 Insulation, FV Outer Front
19 816-0746 Insulation, Foam Deck
20 823-7824
Frypot, FV OCF with filter prior to 07/2014
823-8975
Frypot, FV OCF with filter after 06/2014
823-8022
Frypot, FV OCF without filter prior to 07/2014
823-8976
Frypot, FV OCF without filter after 06/2014
21 823-7454 Retainer, FV LH Upper Burner
22 823-7455 Retainer, FV RH Upper Burner
23 823-7279 Retainer, FV Front Insulation
24 823-7415 Retainer, FV Outer Front
25 824-2164 Front Upper Seal Weldment, FV LH
26 824-2165 Front Upper Seal Weldment, FV RH
27 900-1031 Retainer, Burner Sight Glass
28 930-0818 Bracket, Flue to Pot
29 900-4253 Strip, Fluecap Retainer
30 900-1049 Retainer, Plenum Gasket
31 816-0057 Gasket, Plenum
32 823-8574
Plenum, Full-Vat (use 823-8590 for CE and export Non-CE units)
* 816-0059 Gasket, Ignitor
* Not illustrated.
√ Recommended parts.
