2-17
2.7.2 Dual-Vat Frypot Components cont.
ITEM PART # COMPONENT
108-2223SP Frypot Assy Dual-Vat OCF with filter (NAT)
108-2225 Frypot Assy Dual-Vat OCF with filter (PRO)
108-2845 Frypot Assy Dual-Vat OCF non-filter (NAT)
108-2844 Frypot Assy Dual-Vat OCF non-filter (PRO)
* 826-2596 Insulation Kit, Complete Dual-Vat
* 826-2593 Insulation Kit, Burner Dual-Vat
1 108-2898 Flue Assembly, Dual-Vat
2 106-7960 Plate Assembly, Dual-Vat Collector
3 220-6530 Retainer, Dual-Vat Upper Insulation
4 220-7916 Retainer, Dual-Vat Outer Frypot
5 220-6180 Back, Dual-Vat Lower Combustion Chamber
6 220-2920 Brace, Foam Deck Insulation
7 220-2972 Brace, Dual-Vat Rear Insulation
√ 8 810-3435 Burner, Universal Replacement
9 812-0356 Insulation, Burner Sight Glass
10 816-0900 Insulation, Burner
11 812-0706 Insulation, Upper Burner Rail
12 812-1029 Insulation, Combustion Chamber Side
13 814-0048SP Glass, Burner Sight
14 816-0838 Insulation, Dual-Vat Rear Lower
15 816-0741 Insulation, Dual-Vat LH/RH Front Seal
16 816-0742 Insulation, Dual-Vat Lower Inner Front
17 816-0743 Insulation, Dual-Vat Front Upper
18 816-0979 Insulation, Dual-Vat Outer Front
19 816-0746 Insulation, Foam Deck
20 812-0688 Insulation, Flue Collection
21 823-7457 Retainer, Dual-Vat RH Upper Burner
22 823-7456 Retainer, Dual-Vat LH Upper Burner
23 823-7416 Retainer, Dual-Vat Front Insulation
24 823-7417 Retainer, Dual-Vat Outer Front
25 824-1796 Riser W/A Dual-Vat Pot
26 824-2166 Dual-Vat LH Upper W/A Seal
27 824-2167 Dual-Vat RH Upper W/A Seal
28 900-1031 Retainer, Burner Sight Glass
29 930-0818 Bracket, Flue to Pot
30 900-4253 Strip, Fluecap Retainer
31 900-1049 Retainer, Plenum Gasket
32 816-0057 Gasket, Plenum
* 816-0059 Gasket, Ignitor
33 823-8573
Plenum, Dual-Vat (use 823-8589 for CE and export Non-CE units)
34 823-7862
Frypot, Dual-Vat OCF with filter prior to 07/2014
823-8973
Frypot, Dual-Vat OCF with filter after 06/2014
823-8020
Frypot, Dual-Vat OCF without filter prior to 07/2014
823-8974
Frypot, Dual-Vat OCF without filter after 06/2014
* Not illustrated.
√ Recommended parts.
