2-20
2.8 Gas Valves, Supply and Combustion System Components cont.
ITEM PART # COMPONENT
4 Orifice, Burner
810-3977 1.88mm 75% Butane/25% Butane (Standard Elevation)
** 810-3865 1.95mm Propane/Butane (G30, G31) Australia Only
** 810-3860 2.05 mm Propane/Butane (G30, G31) (0-4999 Ft, 0-1524 M)
** 810-3863 2.10 mm Propane/Butane (G30, G31) (5000-6999 Ft, 1525-2133 M)
** 810-3867 2.84mm Natural Gas (G20, G25) Australia Only DV
** 810-3866 2.92mm Natural Gas (G20, G25) Australia Only FV
** 810-3864 3.18 mm Natural Gas (G20, G25) (0-4999 Ft, 0-1524 M) CE
** 810-3861 3.26 mm Natural Gas (G20, G25) (0-4999 Ft, 0-1524 M)
** 810-3862 3.40 mm Natural Gas (G20, G25) (5000-6999 Ft, 1525-2133 M)
√ 5 108-1455 Switch, Air Pressure Assembly (807-2141 switch alone)
√ 6 Valve, Non-CE Gas
826-1122 Natural Gas (G20, G25)
826-1120 Kit Natural Gas w/ flexlines and hardware
826-1123 Propane Gas (G30, G31)
826-1121 Kit, Propane Gas w/ flexlines and hardware
√ 7 810-1715 Valve, CE Gas (G20, G25, G30, G31)
8 810-1041 Accessory Kit (contains parts to adapt Item 7 to specific fryer configuration)
9 810-0691 Tube, ⅛-inch Vent
10 806-9678SP Plug Assy, CE Gas Valve
11 813-0304 Bushing, ½-inch NPT to ¼-inch NPT Flush Reducing
12 813-0700 Nipple, ¼-inch NPT x 3-inch
13 813-0302 Elbow, ¼-inch Male NPT to ⅜-inch Tube 90° (used on DV valve)
14 813-0449 Tee, ¼ -inch NPT Brass
15 810-3147 Bushing, ¾-inch OD x ½ -inch ID NPT Flush
16 813-0340 Adapter, ⅛-inch NPT to ⅛-inch Tube
17 810-3807 Tube, ⅛-inch OD X 6.5-inch Enrichment
18 813-0154 Plug, ⅛-inch NPT Hex Head Pipe
19 813-0378 Fitting, ⅛-inch NPT Cross
20 813-0354 Elbow, ⅛-inch NPT X ⅛-inch Tube Compression
21 810-1026 Tee, ¼-inch Male NPT to Female NPT Street
22 810-1025 Connector, ¼-inch Male NPT to ⅜-inch Tube
23 813-0495 Tee, ¼-inch Male NPT to Female NPT
24 810-1006 Bushing, ¼-inch NPT to ⅛-inch NPT Reducing
25 810-1176 Tap, ⅛-inch NPT Pressure
26 813-0301 Tee, ¼-inch Male NPT to ⅜-inch Tube
27 810-1353 Gas Line, ⅜-inch OD X 9-inch SS Flexible (Used on some split pots)
28 810-1355 Gas Line, ⅜-inch OD X 15-inch SS Flexible
* 826-3278 Conversion Kit, Natural Gas FV (G20, G25) to Propane/Butane(G30,G31) Non-CE
* 826-3279 Conversion Kit, Natural Gas DV (G20, G25) to Propane/Butane(G30,G31) Non-CE
* 826-2967 Conversion Kit, Propane/Butane FV(G30, G31) to Natural Gas (G20,G25) Non-CE
* 826-2968 Conversion Kit, Propane/Butane DV(G30, G31) to Natural Gas (G20,G25) Non-CE
* 826-2969 Conversion Kit, Nat Gas FV (G20, G25) to Prop/Butane(G30,G31) Aust Non-CE
* 826-2970 Conversion Kit, Nat Gas DV (G20, G25) to Prop/Butane(G30,G31) Aust Non-CE
* 826-2971 Conversion Kit, Prop/But FV(G30, G31) to Natural Gas (G20,G25) Aust Non-CE
* 826-2972 Conversion Kit, Prop/But DV(G30, G31) to Natural Gas (G20,G25) Aust Non-CE
* 826-3278 Conversion Kit, Nat Gas (G20, G25) to Prop/Butane(G30,G31) CE
* 826-2976 Conversion Kit, Prop/But (G30, G31) to Natural Gas (G20,G25) CE
* Not illustrated.
√ Recommended parts.
