Fuji Xerox DocuCentre-V C2263 Administrator's Guide

Connectivity & Network Setup
207
Tools
5
HTTP Proxy Server Port Number
Set the HTTP proxy server port number from 1 to 65535.
The default value is 8080.
Important
z
Do not use the numbers assigned to the other ports.
HTTP Proxy Server Authentication
Select [Enabled] when authentication is required to connect to the HTTP proxy server.
HTTP Proxy Server Login Name
Enter a login name of the HTTP proxy server. Up to 31 characters are allowed.
HTTP Proxy Server Password
Enter a password of the HTTP proxy server. Up to 31 characters are allowed.
HTTPS Proxy Server Name
Enter the HTTPS proxy server name or the IP address. Up to 255 characters are allowed.
You can specify the addresses by IPv4 address, IPv6 address, and FQDN.
HTTPS Proxy Server Port Number
Set the HTTPS proxy server port number from 1 to 65535.
The default value is 8080.
Important
z
Do not use the numbers assigned to the other ports.
HTTPS Proxy Server Authentication
Select [Enabled] when authentication is required to connect to the HTTPS proxy server.
HTTPS Proxy Server Login Name
Enter a login name of the HTTPS proxy server. Up to 31 characters are allowed.
HTTPS Proxy Server Password
Enter a password of the HTTPS proxy server. Up to 31 characters are allowed.
EP Proxy Server Setup
Configure the settings for a proxy server for EP connection when the EP system via the
Internet is used.
Important
z
Configure the settings when the EP system via the Internet is used.
Reference
z
For information on EP system, refer to "EP System" (P.749).

Fuji Xerox DocuCentre-V C2263 Specifications

General

Print Resolution	1200 x 2400 dpi
Scan Resolution	600 x 600 dpi
Functions	Print, Copy, Scan, Fax
Memory (Standard)	1GB
Duplex Printing	Yes
Fax Transmission Speed	33.6 kbps
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Paper Size	A4, A5, B5
Hard Disk Drive	160 GB
