Paper Jams
617
Problem Solving
15
Paper Jams in Bottom Left Cover B (for 2-tray configuration)
The following describes how to clear paper jams occurring in the bottom left cover.
1
Gently open the bottom left cover B while pulling the release lever.
2
Remove the jammed paper.
z
Paper may be jammed in the hidden area on the upper position. Check inside thoroughly.
z
If the paper is torn, make sure no piece of paper remains inside the machine.
3
Close the bottom left cover B gently.
Paper Jams in Bottom Left Cover B (for 4-tray configuration)
1
Gently open the bottom left cover C while pulling the release lever.
To Next Page
