Activity Report
747
Appendix
16
Duration The duration of the transmission is displayed. In Batch Send, it is
the length of time taken to transmit each document is recorded.
Pages "-" is shown when the number of pages is 0.
z
Transmitting
The number printed on the left side of the slash "/" indicates the
number of pages that were successfully transmitted. The
number printed on the right side of the slash "/" indicates the
number of total pages. In Batch Send, the number of total
pages is not shown.
z
Receiving/Polling
The number of pages that the machine successfully received is
shown.
z
Depending on the transmission status on the recipient's machine or
the setting of the machine, the value in [Pages] may differ from the
actual number of pages printed.
Mode The mode used for the communication is shown.
There are three modes: G3, EC, and SG3 (Super G3). (Thisfield is
blank if a mode other than above these was used.)
When IP Fax (SIP) is used:
IP Fax or IP Fax-ECM
Contents The information about the communication is indicated. See the
Note field at the bottom of the report for a list of abbreviations
and their definitions.
z
Transmitting
1 Remote service
2 Redial
3 Folder XXX
4 Broadcast/Multi-Poll
5 Polling
6 Relay Broadcast Assignment
7 Fax forwarding box XXX
When IP Fax (SIP) is used:
1 Redial
2 Folder XXX
3 Broadcast/Multi-Poll
4 Polling
z
Receiving
1 Folder XXX
2 Polling
3 Receiving line box XXX
When IP Fax (SIP) is used:
1 Folder XXX
2 Polling
3 Receiving line box XXX
z
XXX indicates the Folder number
Status The result of the operation is indicated.
Completed : The operation ended normally.
Busy : The recipient is busy or did not answer.
Auto Send : The document is being re-sent and the set re-
send times has not been exceeded.
Canceled : The communication was terminated.
Item Description
