312 7 Maintenance
6. While pushing down the black portion next
to the rollers with your left hand (1), slip the
cleaned rollers on the axle (2).
7. While aligning the projection on the tray
retard roller with the notch on the axle (1),
and keeping the tab up.(2), slip the tray
retard roller all the way on the axle.
8. Firmly push the paper tray all the way back
into the printer.
Cleaning the Bypass Feed Roller Unit
Feeding illustrated postcards or paper with a lot of paper dust may cause image transfer
prevention powder or dust to adhere to the paper rollers and make paper feed impossible.
If paper feed becomes impossible, thoroughly wipe the paper feed rollers and retard rollers
with a moistened and then thoroughly wrung cloth using the procedure described below.
1. Open the bypass tray.
To Next Page
