344 A Appendix
Removing the Parallel Port Kit (Optional)
This section describes how to remove the Parallel Port Kit (Optional) on the printer. Refer
to the steps in the “Installing the Parallel Port Kit (Optional)” (P. 341) above for the detailed
instructions as the similar steps are explained simply.
1. Switch the power off by pressing the < >
side of the power switch of the printer.
After checking that the display of the control
panel and the various lamps have switched
off, unplug the power cord from the power
outlet and the printer.
Important
• The electric parts on the inside of the right cover of the
printer can get very hot. Before installing extension
system memory, be sure to first switch off the power of
the printer, wait for approximately 40 minutes, and
check that the temperature inside the printer has
cooled down.
2. Loosen the screw of the rear panel of the
printer, slide the right cover backward, and
remove the cover by pulling the lower side
of the cover towards you.
3. Using a coin, etc., loosen the two screws at
the bottom of the inner cover and remove
the cover.
4. Loosen the two screws that secure the
parallel port kit (optional), and remove the
parallel port kit (optional) from the controller
board.
Parallel Port Kit (Optional) removal is now complete.
If the installation of other options is not needed, attach the dummy plate removed in step 3
of the installation procedure. Then close the internal cover and the right cover, in this order,
and secure them with their respective screws.
