Home > Network > Technical Information for Advanced Users > Gigabit Ethernet (Wired Network
Only) > Configure the Gigabit Ethernet Settings Using Web Based Management
Configure the Gigabit Ethernet Settings Using Web Based Management
1. Start your web browser.
2. Type "http://machine's IP address" in your browser's address bar (where "machine's IP address" is the
machine's IP address).
For example:
http://192.0.2.1
3. Type a password, and then click
. The default password is "x-admin". To ensure security, it is important
you change the password.
4. Click the Network tab.
5. Click Wired.
6. Click Ethernet in the left navigation bar.
7. Select Auto from the Ethernet Mode drop-down list.
8. Click Submit.
9. To enable the settings, restart your machine.
You can confirm your settings by printing the Network Configuration Report.
Related Information
• Gigabit Ethernet (Wired Network Only)
Related Topics
• Print the Network Configuration Report
371
