3.8 Correcting skewed Documents
3.8 Correcting skewed Documents
You can set the scanner to automatically detect and correct skewed documents that are fed into the ADF.
The configuration is done through the scanner driver.
The following shows the procedure for changing the setting from the [TWAIN Driver] dialog box.
1. Start TWAIN Driver from your scanning application.
Refer to “2.13 How to use the Scanner Driver” on page 41.
2. Click the [Option...] button in the [TWAIN Driver] dialog box.
⇒ The dialog box appears.
3. Click the [Rotation] tab.
To Next Page
