175
8.4 Multifeed Detection
8
SCANNER SETTINGS
8.4 Multifeed Detection
Multifeed refers to the phenomenon, when two or more documents are fed overlapping at once into the
scanner.
This may cause the loss of important data.
To prevent this, this scanner is equipped with a Multifeed detection function.
When function is activated, a message will be displayed and the scanning interrupted in case a Multifeed
has been detected.
Configure the settings for the Multifeed detection as follows.
1. Start up the Software Operation Panel.
Refer to “8.1 Scanner Settings” on page 166.
2. From the [Device Setting 2] tab select “Multifeed”.
3. Select the detection method.
Deactivated: No Multifeed detection will be performed.
Check overlapping: Document overlapping will be monitored.
Check length difference: The difference of the documents length will be monitored.
Check overlapping and
length difference:
[Check overlapping] and [Check length difference], both parameters will
be used for monitoring the fed documents.
Length: When checking the document length, select the length difference for
which a Multifeed will be detected. Select 10/15/20mm. If the detected
document length is smaller than the selected size, it will be recognized as a
Multifeed.
To Next Page
