8.12 SCSI Bus Width
8.12 SCSI Bus Width
When using the SCSI-connected scanner, you can select a data transfer width.
Configure the settings for the SCSI Bus Width as follows:
1. Start up the Software Operation Panel.
Refer to “8.1 Scanner Settings” on page 166.
2. Select the “SCSI Bus Width” setting on the [Device Setting 2] tab.
3. Select either 16-bit or 8-bit.
ATTENTION
To use SCSI cards and/or SCSI cables that do not support Ultra Wide SCSI,
select “8-bit”.
