157
7.4 Hole-punching Prohibited Areas
7
DOCUMENT SPECIFICATIONS
7.4 Hole-punching Prohibited Areas
Punched holes in the shaded areas may cause errors.
For job separation sheet requirements, refer to “7.7 Job Separation Sheet” on page 161.
HINT
If there are any holes in the 35mm wide central column, you can set the doc-
ument a bit to the left or right to avoid detecting error.
Feeding Direction
35
Center line
㧔Unit : mm㧕
15
Reference Point
Front Side
Leading edge
Bottom edge
