18
2.6 Loading Documents on the Hopper
■ Setting the Document
There are 2 ways to set documents on the hopper.
(1) Set the document at the center of the hopper (mainly for document of equal size pages).
(2) Set the document by either side of the hopper (mainly for document of different size pages, or you want
to align the document by the side instead of the center line).
(1) Setting the document at the center of the hopper
1. Load the document on the hopper.
Place the document face-up on the hopper.
2. Adjust the Side guides to the document width.
Pressing the lock lever, slide the Side guides so that they contact the document sides.
If there is space between the document edges and the guides, the scanned images may be
skewed.
Lock lever
Side guide
To Next Page
