35
2.12 Feeding Documents Manually
2
BASIC SCANNER OPERATIONS
■ Single Feed
1. Lift up the Pick roller unit.
Lift up the small plate on the left side using your finger.
⇒ The Pick roller unit will click into place.
⇒ The hopper will move up to the manual feed position.
2. Place documents face-up at the center of the hopper table.
At this moment, do not stick the top edge of the document against the inner side of the hopper,
instead set them a bit apart.
ATTENTION
• If there is any document loaded on the Hopper, remove it before
adjusting.
• Be careful not to get your fingers or anything caught in the mechanism
when the hopper table moves up.
Pick Roller Unit
Hopper
Guide Plate
To Next Page
