Replacing the Consumables
This section explains how to replace the consumables for the scanner.
The inside of the ADF becomes very hot when the scanner is being used.
Before you replace the consumables, make sure to turn off the power, unplug the power
cable and wait for at least 15 minutes for the inside of the ADF to cool down.
Consumables and Replacement Cycles
Name Part No. Suggested Replacement Cycle
BRAKE ROLLER PA03810-0001 200,000 sheets or one year
PICK ROLLER PA03670-0002 200,000 sheets or one year
Consumables need to be replaced periodically. It is recommended that you keep a stock of new consumables
and replace them before it reaches the end of the consumable life. The scanner records the number of sheets
scanned for each consumable (pick roller and brake roller) and the amount of remaining ink (print cartridge),
which allows you to determine when to replace consumables.
● For fi-8190/fi-8290/fi-8170/fi-8270
Use one of the following methods to check the number of sheets that have been scanned and the amount of
remaining ink.
- You can select [5: Consumable counters] from the [Settings Menu] screen on the operator panel to check
the number of sheets that have been scanned and the amount of remaining ink.
For details, refer to How to Use Settings Menu (page 146).
- You can check the number of sheets that have been scanned and the amount of remaining ink in the
Software Operation Panel.
For details, refer to Checking the Sheet Counters (page 352).
● For fi-8150/fi-8250/fi-8150U/fi-8250U
You can check the number of sheets that have been scanned and the amount of remaining ink in the
Software Operation Panel.
231
