Fujitsu fi-8190 User Manual

Scanning Documents That Are 220 mm to 240 mm in Width ....................................................................... 178
Scanning Documents Folded in Half.............................................................................................................. 181
Scanning Documents such as Envelopes or Multi-Layered Transfer Paper .................................................. 184
Scanning Booklets such as Passports............................................................................................................. 187
Scanning Documents Larger than A4/Letter Size.......................................................................................... 190
Scanning Photographs and Clippings without Damaging Them .................................................................. 193
Scanning Booklets such as Passports without Damaging Them................................................................... 195
Scanning Long Page Documents.................................................................................................................... 197
Scanning Books with the Flatbed [fi-8290/fi-8270/fi-8250/fi-8250U] ......................................................... 198
Scanning Large Documents with the Flatbed [fi-8290/fi-8270/fi-8250/fi-8250U] ...................................... 200
Feeding Documents Manually ....................................................................................................................... 202
Configuring Not to Detect Certain Overlap Patterns..................................................................................... 205
Operational Procedure [fi-8190/fi-8290/fi-8170/fi-8270]............................................................................................206
Operational Procedure [fi-8150/fi-8250/fi-8150U/fi-8250U] .......................................................................................210
Disabling the Paper Protection Function [fi-8190/fi-8290/fi-8170/fi-8270]................................................ 212
Operational Procedure ................................................................................................................................................212
Daily Care 214
Cleaning Materials ......................................................................................................................................... 214
Location and Frequency ................................................................................................................................. 216
Cleaning the Outside of the Scanner............................................................................................................. 217
Cleaning the Inside of the Scanner (ADF) with Cleaning Paper................................................................... 219
Cleaning the Inside of the Scanner (ADF) with a Cloth ................................................................................ 222
Cleaning the Inside of the Scanner (Flatbed) [fi-8290/fi-8270/fi-8250/fi-8250U]...................................... 229
Cleaning the (Carrier) Sheet.......................................................................................................................... 230
Replacing the Consumables 231
Consumables and Replacement Cycles .......................................................................................................... 231
Replacing the Brake Roller............................................................................................................................. 233
Replacing the Pick Roller ............................................................................................................................... 238
Troubleshooting 246
When a Paper Jam Occurs .............................................................................................................................. 246
Errors............................................................................................................................................................... 248
Contents
5

Fujitsu fi-8190 Specifications

General

Duplex scanning	Yes
Maximum scan size	216 x 355.6 mm
ADF scan speed (b/w, A4)	90 ppm
Optical scanning resolution	600 x 600 DPI
Black/white scanning color modes	Grayscale, Monochrome
Control type	Buttons
Scanner type	ADF + Manual feed scanner
Product color	Black, Grey
Sensor type	Dual CIS
Scan drivers	ISIS, TWAIN
Scan file formats	JPEG, PDF, PNG, TIFF
Daily duty cycle (max)	- pages
Scanner smart software features	Blank page detection
Auto document feeder (ADF) input capacity	100 sheets
Card thickness (max)	1.4 mm
Paper tray media weight	20 - 465 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Post Card(JPN)
Maximum ISO A-series paper size	A4
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-B
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	30 W
Sustainability certificates	ENERGY STAR, RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	163 mm
Width	170 mm
Height	300 mm
Weight	4000 g
