Number
in figure
Name Quantity Remarks
1 Rail 2 Bilaterally symmetrical
shape
2Cable support (*1) (*2) 1
3Cable support bracket (*2) 2 Bilaterally symmetrical
shape
4M3 screw (*2) 2
5Cable support fixing bracket (*2) 2 Bilaterally symmetrical
shape
6M6 screw 10
7Cage nut 10
*1 There are two types of cable support: Type-1 and Type-2. To distinguish between them, see Figure 3-62.
*2 The Type-2 cable support is an integrated unit consisting of these parts.
Figure 3-61
Rack mount kit
Chapter 3 Installing the System 121
