Table 4-2
Label replacement table
Before change After change
BB04-XBU0-1L Pink -> BB04-XBU0-2L Pink
BB04-XBU0-1L Black -> BB04-XBU0-2L Black
BB04-XBU0-1R Light blue -> BB04-XBU0-2R Light blue
BB04-XBU0-1R Black -> BB04-XBU0-2R Black
BB04-XBU1-1L Pink -> BB04-XBU1-2L Pink
BB04-XBU1-1L Black -> BB04-XBU1-2L Black
BB04-XBU1-1R Light blue -> BB04-XBU1-2R Light blue
BB04-XBU1-1R Black -> BB04-XBU1-2R Black
BB05-XBU0-1L Pink -> BB05-XBU0-2L Pink
BB05-XBU0-1L Black -> BB05-XBU0-2L Black
BB05-XBU0-1R Light blue -> BB05-XBU0-2R Light blue
BB05-XBU0-1R Black -> BB05-XBU0-2R Black
BB05-XBU1-1L Pink -> BB05-XBU1-2L Pink
BB05-XBU1-1L Black -> BB05-XBU1-2L Black
BB05-XBU1-1R Light blue -> BB05-XBU1-2R Light blue
BB05-XBU1-1R Black -> BB05-XBU1-2R Black
BB06-XBU0-1L Pink -> BB06-XBU0-2L Pink
BB06-XBU0-1L Black -> BB06-XBU0-2L Black
BB06-XBU0-1R Light blue -> BB06-XBU0-2R Light blue
BB06-XBU0-1R Black -> BB06-XBU0-2R Black
BB06-XBU1-1L Pink -> BB06-XBU1-2L Pink
BB06-XBU1-1L Black -> BB06-XBU1-2L Black
BB06-XBU1-1R Light blue -> BB06-XBU1-2R Light blue
BB06-XBU1-1R Black -> BB06-XBU1-2R Black
BB07-XBU0-1L Pink -> BB07-XBU0-2L Pink
BB07-XBU0-1L Black -> BB07-XBU0-2L Black
BB07-XBU0-1R Light blue -> BB07-XBU0-2R Light blue
BB07-XBU0-1R Black -> BB07-XBU0-2R Black
BB07-XBU1-1L Pink -> BB07-XBU1-2L Pink
BB07-XBU1-1L Black -> BB07-XBU1-2L Black
BB07-XBU1-1R Light blue -> BB07-XBU1-2R Light blue
BB07-XBU1-1R Black -> BB07-XBU1-2R Black
c. Connect the crossbar cables to 2L and 2R of crossbar unit #0/#1.
Mount the cables according to the labels.
