Fujitsu M10 User Manual

4-11).
A
A
0L
0R
1L
1R
2L
2R
1R
0R
0L
1L
2L
2R
0L
0R
1L
1R
2L
2R
1R
0R
0L
1L
2L
2R
XBU#0 XBU#1
Figure 4-11
Crossbar cable (optical) shapes and tabs
3.
Move the BB#07 cross bar cables (optical) from BB#04.
a. Remove the crossbar cables from 1L and 1R of crossbar unit #0/#1.
Figure 4-12
Moving BB#07 cables from BB#04
b. Replace the labels on the removed cables.
The replacement labels are supplied with expansion rack
2. Referring to Table
4-2, replace the labels.
Fujitsu M10/SPARC M10 Systems Installation Guide
･
July 2015152
