Table 1-4
Workflow for the SPARC M10-4S
Step (work time (*1)) Work description Referenc e
Installation work (approx. 160 minutes (*2))
1Check the latest information available
in the Fujitsu M10/SPARC M10 Systems
Product Notes.
Fujitsu M10/SPARC M10 Systems
Product Notes
Required
2 Before installing the system, check the
safety precautions, system specifications,
and necessary conditions for
installation.
"Chapter 2 Planning and Preparing
for System Installation"
Required
3 Prepare the necessary tools/
information for installation.
"3.1 Preparing the Necessary
Tools/Information for Installation"
Required
4 Confirm the delivered components. "3.2.3 Confirming the delivered
components of the SPARC M10-4S"
Required
5 Install the rack. See the manual for each rack.
"3.3.2 Securing
the rack"
Required
6Mount the chassis in the rack. "3.4.2 Mounting the SPARC
M10-4/SPARC M10-4S in a rack"
Required
7If there are optional components,
mount them on the chassis.
"3.5.2 Mounting optional
components in the SPARC
M10-4/SPARC M10-4S"
Optional (*3)
8Set the ID required for identifying each
chassis.
"4.1 Setting the ID (BB-ID)
Identifying a Chassis"
Required
9 Connect crossbar cables, XSCF BB
control cables, and the XSCF DUAL
control cable to the chassis.
"4.2 Connecting Cables (for Direct
Connections between Chassis)"
Required
10 Connect serial cables, LAN cables, and
power cords to the
chassis.
"5.2 Connecting Cables to the
SPARC M10-4/SPARC M10-4S"
Required
11 Store the connected cables in the rack. "5.5 Storing Cables" Required
Initial diagnosis (approx. 100 minutes)
12 Connect the system management
terminal to the chassis.
"6.1 Connecting the System
Management Terminal to the Chassis"
Required
13 Confirm that the chassis identification
IDs (BB-IDs) are set.
"6.2.1 Checking the BB-ID settings
(for the SPARC M10-4S)"
Required
14 Turn on the input power. "6.2.2 Turning on the input power
and starting the XSCF"
Required
The number shown after BB# is the ID (BB-ID) identifying a chassis. The BB-IDs of
the SPARC M10-4S are set, starting at 00.
By clicking a reference in " " to display a section, you can see the details of the
respective step.
Chapter 1 Understanding the Installation Flow 7
