Number in figure D escription
1SPARC M10-4S
2 Crossbar unit
3 Crossbar cable (optical)
4 Crossbar box
Table 1-5
Workflow for connections through crossbar boxes
Step (work time (*1)) Work description Reference
Installation work (approx. 59 minutes/approx. 280 minutes (*2))
1Check the latest information available
in the Fujitsu M10/SPARC M10 Systems
Product Notes.
Fujitsu M10/SPARC M10 Systems
Product Notes
Required
2 Before installing the system, check the
safety precautions, system spe cifications,
and necessary conditions for
installation.
"Chapter 2 Planning and Preparing
for System Installation"
Required
3Prepare the necessary tools/
information for installation.
"3.1 Preparing the Necessary
Tools/Information for Installation"
Required
4Confirm the delivered components. "3.2.3 Confirming the delivered
components of the SPARC M10-4S"
"3.2.5 Confirming the delivered
components of an expansion rack"
Required
5 Before installing the rack, connect the
power cords to a power distribution
unit (PDU) of the rack.
"3.3.1 Connecting the power cords
to the power distribution units of an
expansion rack"
Required
6Install the rack. See the manual for each rack.
"3.3.2 Securing the rack"
Required
7If there are two racks, connect them. "
3.3.3 Connecting racks" Required
8If there are optional components,
mount them on the chassis.
"3.5.2 Mounting optional
components in the SPARC
M10-4/SPARC M10-4S"
Optional (*3)
9Set the ID required for identifying each
chassis.
"4.1 Setting the ID (BB-ID)
Identifying a Chassis"
Required
(*4)
10 Connect crossbar cables, XSCF BB
control cables, and the XSCF DUAL
control cable to the chassis.
"4.3.2 Connecting crossbar cables"
"4.3.3 Connecting XSCF cables"
Required
(*5)
11 Connect serial cables, LAN cables, and
power
cords to crossbar boxes.
"5.4 Connecting Cables to a
Crossbar Box"
Required
The number shown after BB# or XBBOX# is the ID (BB-ID) identifying the unit. The
IDs of the SPARC M10-4S are set, starting at 00. The IDs of crossbar boxes are set,
starting at 80.
By clicking a reference in " " to display a section, you can see the details
of the
respective step.
Fujitsu M10/SPARC M10 Systems Installation Guide
･
July 201510
