Fujitsu M10 User Manual

XSCF>

showsscp
Note -
For details on the default SCCP IP address, see "3.7.5 Understanding the IP addresses
that are set with SSCP" in the Fujitsu M10/SPARC M10 Systems System Operation and
Administration Guide.
XSCF>

poweroff

-y

-a
Remarks -
When installing the M10-4S in an existing expansion rack, you need to remove the
protection bracket and blank panel of the mounting space (A in Figure 9-3). Note that there
are cases where no protection bracket is attached, depending on the installation. The blank
panel is secured with two M6
screws. The protection bracket is secured with four M6 screws.
1.
Log in to the master XSCF.
2.
Execute the showsscp command to check whether the IP address of the SP to
SP communication protocol (SSCP) is a default value or a value set by a user.
If the IP address is a default value and the default value should also be used
for
the IP address of the SPARC M10-4S to be installed, go to the next step.
To set a user value, use the setsscp command to set an IP address, use the
applynetwork command to apply the SSCP IP address of the target SPARC
M10-4S, and confirm that it was reflected.
Then, execute the rebootxscf
command to complete settings, and go to the next step. For details on the
procedure, see "3.7.15 Reflecting the XSCF network settings" in the Fujitsu
M10/SPARC M10 Systems System Operation and Administration Guide.
3.
Execute the poweroff command to stop the system.
4.
Remove the power cords
of all the chassis from the input power.
5.
Mount the target SPARC M10-4S in the rack.
For the mounting procedure, see "3.4.2 Mounting the SPARC M10-4/SPARC
M10-4S in a rack."
Chapter 9 Installing a System with a Building Block Configuration 261
